Rockwell Automation Allen-Bradley SMC-Flex 150

Appendix B
Parameter Information
Table B.1 Parameter List
Group
Parameter
Description
Parameter
Number
Units
Min./
Max.
Default
Settings
User
Settings
Metering Volts Phase A-B 1 V
Metering Volts Phase B-C 2 V
Metering Volts Phase C-A 3 V
Metering Current Phase A 4 A
Metering Current Phase B 5 A
Metering Current Phase C 6 A
Metering Watt Meter 7 KW/MW
Metering Kilowatt Hours 8 KWH/MWH
Metering Elapsed Time 9 Hours
Metering Meter Reset 10 Ready
ETM Reset
KWH Reset
Ready
Metering Power Factor 11 0.00…0.99
Metering Mtr Therm Usage 12 % 0…100
Metering Motor Speed 13 % 0…100
Basic Set Up SMC Option 14 Standard
Brake
Pump Control
Basic Set Up Motor Connection 15 Line/Delta Line
Basic Set Up Line Voltage 16 V 0…10000 480
Basic Set Up Starting Mode 17 Full Voltage
Current Limit
Soft Start Linear Speed
Pump Start
Soft Start
Basic Set Up Ramp Time 18 SEC 0…30 10
Basic Set Up Initial Torque 19 %LRT 0…90 70
Basic Set Up Cur Limit Level 20 %FLC 50…600 350
Basic Set Up Torque Limit 21 %LRT 0…100 90
Basic Set Up Kickstart Time 22 SEC 0.0…2.0 0.0
Basic Set Up Kickstart Level 23 %LRT 0…90 0
Basic Set Up Option 2 Input 24 Disable
Dual Ramp
Preset SS
Disable
Dual Ramp Starting Mode 2 25 Full Voltage
Current Limit
Soft Start
Linear Speed
Soft Start
Dual Ramp Ramp Time 2 26 SEC 0…30 10
Dual Ramp Initial Torque 2 27 %LRT 0…90 70
Dual Ramp Cur Limit Level 2 28 %FLC 50…600 350
Dual Ramp Torque Limit 2 29 %LRT 0…100 90
