B-2 Parameter Information
Dual Ramp Kickstart Time 2 30 SEC 0.0…2.0 0.0
Dual Ramp Kickstart Level2 31 %LRT 0…90 0
Basic Set Up Stop Mode 32 Disable
Soft Stop
Linear Speed
SMB
Accu-Stop
Disable
Basic Set Up Stop Time 33 SEC 0…120 0
Basic Set Up/ Accu-Stop Braking Current 35 %FLC 0…400 0
Preset SS/ Accu-Stop Slow Speed Sel 39 SS Low
SS High
SS High
Preset SS/ Accu-Stop Slow Speed Dir 40 SS FWD
SS REV
SS FWD
Preset SS/ Accu-Stop Slow Accel Cur 41 %FLC 0…450 0
Preset SS/ Accu-Stop Slow Running Cur 42 %FLC 0…450 0
Accu-Stop Stopping Current 43 %FLC 0…400 0
Basic Set Up/ Overload Overload Class 44 Disable
Class 10
Class 15
Class 20
Class 30
Disable
Basic Set Up/ Overload Service Factor 45 0.01…1.99 1.15
Basic Set Up/ Overload Motor FLC 46 A 1.0…1000.0 1.0
Basic Set Up/ Overload Overload Reset 47 Manual
Auto
Manual
Overload Overload A Lvl 50 %MTU 0…100 0
Underload Underload F Lvl 51 %FLC 0…99 0
Underload Underload F Dly 52 SEC 0…99 0
Underload Underload A Lvl 53 %FLC 0…99 0
Underload Underload A Dly 54 SEC 0…99 0
Undervoltage Undervolt F Lvl 55 %V 0…99 0
Undervoltage Undervolt F Dly 56 SEC 0…99 0
Undervoltage Undervolt A Lvl 57 %V 0…99 0
Undervoltage Undervolt A Dly 58 SEC 0…99 0
Overvoltage Overvolt F Lvl 59 %V 0…199 0
Overvoltage Overvolt F Dly 60 SEC 0…99 0
Overvoltage Overvolt A Lvl 61 %V 0…199 0
Overvoltage Overvolt A Dly 62 SEC 0…99 0
Unbalance Unbalance F Lvl 63 % 0…25 0
Unbalance Unbalance F Dly 64 SEC 0…99 0
Unbalance Unbalance A Lvl 65 % 0…25 0
Unbalance Unbalance A Dly 66 SEC 0…99 0
Jam Jam F Lvl 67 %FLC 0…1000 0
Jam Jam F Dly 68 SEC 0…99 0
Jam Jam A Lvl 69 %FLC 0…1000 0
Jam Jam A Dly 70 SEC 0…99 0
Table B.1 Parameter List (Continued)
Group
Parameter
Description
Parameter
Number
Units
Min./
Max.
Default
Settings
User
Settings
