60 Rockwell Automation Publication 520-UM001I-EN-E - July 2016
Chapter 2 Start Up
6. Verify that the Sink (SNK)/Source (SRC) jumper is set to match your
control wiring scheme. See the PowerFlex 523 Control I/O Wiring Block
Diagram on page 38 and PowerFlex 525 Control I/O Wiring Block
Diagram on page 42 for location.
7. Wire I/O as required for the application.
8. Wire the power input and output terminals.
9. Confirm that all inputs are connected to the correct terminals and are
secure.
10. Collect and record motor nameplate and encoder or feedback device
information. Verify motor connections.
• Is the motor uncoupled?
• What direction will the motor need to turn for the application?
11. Verify the input voltage to the drive. Verify if the drive is on a grounded
system. Ensure the MOV jumpers are in the correct position. See AC
Supply Source Considerations on page 19 for more information.
12. Apply power and reset the drive and communication adapters to factory
default settings. To reset the drive, see parameter P053
[Reset to Defalts].
To reset the communication adapters, see the user manual of the adapter
for more information.
13. Configure the basic program parameters related to the motor. See Smart
Start-Up with Basic Program Group Parameters on page 65.
14. Complete the autotune procedure for the drive. See parameter P040
[Autotune] for more information.
15. If you are replacing a drive and have a backup of the parameter settings
obtained using the USB utility application, use the USB utility application
to apply the backup to the new drive. See Using the USB Port
on page 67
for more information.
Otherwise, set the necessary parameters for your application using the
LCD keypad interface, Connected Components Workbench, or RSLogix
or Logix Designer if using an Add-on Profile through EtherNet/IP.
• Configure the communication parameters needed for the application
(node number, IP address, Datalinks in and out, communication rate,
speed reference, start source, and so on). Record these settings for your
reference.
• Configure the other drive parameters needed for the drive analog and
digital I/O to work correctly. Verify the operation. Record these
settings for your reference.
The default control scheme is Source (SRC). The Stop terminal is jumpered to
allow starting from the keypad or comms. If the control scheme is changed to
Sink (SNK), the jumper must be removed from I/O Terminals 01 and 11 and
installed between I/O Terminals 01 and 04.
