Rockwell Automation PowerFlex 40 Installation Instructions

Publication 23B-IN001G
Appendix B
Replacement Parts
Table B.A Components
Description Designation Voltage HP Part Number Manufacturer
Motor Circuit
Protector
Option P3 or P3T
MCP1 480V AC 0.5 140M-C2E-B40
(2)
(2) Part of Motor Circuit Protector Replacement Kit.
Allen-Bradley
1.0 140M-C2E-B63
(2)
Allen-Bradley
2.0 140M-D8E-C10
(2)
Allen-Bradley
3.0 140M-D8E-C16
(2)
Allen-Bradley
5.0 140M-D8E-C25
(2)
Allen-Bradley
7.5 140M-F8E-C25
(2)
Allen-Bradley
10 140M-F8E-C32
(2)
Allen-Bradley
15 140M-F8E-C45
(2)
Allen-Bradley
Replacement Kit
(1)
Option P3
(1) Replacement Kit includes Motor Circuit Protector and top and bottom terminal labels/instructions. Does not
include handle, adaptor, or connection rod.
MCP1 480V AC 0.5 363326 Allen-Bradley
1.0 363333 Allen-Bradley
2.0 363337 Allen-Bradley
3.0 363341 Allen-Bradley
5.0 363345 Allen-Bradley
7.5 363349 Allen-Bradley
10 363353 Allen-Bradley
15 363357 Allen-Bradley
Operator Handle
Option P3 or P3T
MCP1 480V AC 0.5-5
7.5-15
190-HS4
140M-C-DN66
Allen-Bradley
Allen-Bradley
Operator Handle
Adaptor Option P3
or P3T
MCP1 480V AC 0.5-15 140M-D-HA Allen-Bradley
Operator Shaft
Option P3 or P3T
MCP1 480V AC 0.5-5
7.5-15
194R-NX12
140M-C-DS
Allen-Bradley
Allen-Bradley
Operator Terminal
Markings
MCP1 480V AC 0.5-5.0 A46006-086-01
(2)
140M-C-TE
(2)
Allen-Bradley
Allen-Bradley
7.5-15 A46006-091-01
(2)
140M-F-TE
(2)
Allen-Bradley
Allen-Bradley
Disconnect Switch
Option P6 or P6T
DS1 480V AC 0.5-10 194R-NJ030P3 Allen-Bradley
15 194R-NJ060P3 Allen-Bradley
Operator Handle
Option P6 or P6T
DS1 480V AC 0.5-15 194R-HS4 Allen-Bradley
Operator Shaft
Option P6 or P6T
DS1 480V AC 0.5-15 194R-R1 Allen-Bradley
Main Fuses
Option P6 or P6T
F1, F2, F3 480V AC 0.5 LPJ-3SP Bussman
AJT-3 Ferraz-Shawmut
1.0 LPJ-6SP Bussman
2.0 LPJ-10 Bussman
LPJ-10SP Bussman
AJT-10 Ferraz-Shawmut
3.0 LPJ-15 Bussman
LPJ-15SP Bussman
5.0 LPJ-20 Bussman
LPJ-20SP Bussman
AJT-20 Ferraz-Shawmut
7.5 LPJ-25 Bussman
LPJ-25SP Bussman
AJT-25 Ferraz-Shawmut
10 LPJ-30 Bussman
LPJ-30SP Bussman
AJT-30 Ferraz-Shawmut
15 LPJ-50 Bussman
LPJ-50SP Bussman
