15 of 136
3. Press the Stop button to clear the fault from the drive.
4. Press the Esc button until you see zero speed on the keypad display.
5. Press the Select button and use the Up or Down arrows until you see the Basic
Program group on the HIM display.
6. Press the Enter or Sel button to enter the Basic Program group. The right digit of the last viewed
parameter in that group will flash.
7. Use the Up or Down arrows until you see P053. If you wait one (1) second, you will
notice that the HIM display scrolls with “P053 – Reset to Defaults”.
Note: Rather than pressing the Up and Down arrows to scroll through many
parameters in numerical order, you can also press Sel button to move from digit to digit or bit to bit. The
digit or bit that you can change will flash.
8. Once P053 is displayed, Press the Enter button. You will see “0 - Ready/Idle” scroll across the
display. Press the Up or Down arrows until you see “2 – Factory Reset”.
