3. Make sure “All Parameters” is selected within the Group dropdown selection box and then click the “Show
Non-Defaults” button as shown below.
A progress window showing the upload will appear.
4. Once the upload has completed you will see the parameters window update to just show only the non-
default parameters.
5. Close the Port 0 Parameters dialog box by clicking
6. You can do the same with the option modules. Select the select the ‘25-COMM-E2P’ tab, then click
‘Parameters’. When the Port 2 Parameters dialog box opens, click ‘Show Non-Default’ button. Take a look,
you will notice that the parameters you changed in Part 1 appear in this list.
7. Click the “Show All” button to return to viewing all of the 25-COMM-E2P parameters.
8. Close the Port 2 Parameters dialog box by clicking the
