Rockwell PowerFlex 70 User Manual

Supplemental Drive Information A-17
Table A.D 600 Volt AC Input Protection Devices
Drive Catalog Number
Frame
(1)
(1)
For IP 66 (NEMA Type 4X/12) enclosures, drives listed as Frame A increase to Frame B and drives listed as Frame C increase to Frame D.
HP Rating
Input Ratings Output Amps
Dual Element Time Delay Fuse
Non-Time Delay Fuse
Circuit Breaker
(4)
(4)
Circuit Breaker - inverse time breaker. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum.
Motor Circuit Protector
(6)
(6)
Motor Circuit Protector - instantaneous trip circuit breaker. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum.
140M Motor Starter with Adjustable Current Range
(7)
(8)
(7)
Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip.
(8)
Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 208 Wye or Delta, 240 Wye or Delta, 480Y/277 or 600Y/347. Not UL listed for use on 480V or 600V Delta/Delta systems.
ND HD Amps kVA Cont. 1 Min. 3 Sec. Min.
(2)
(2)
Minimum protection device size is the lowest rated device that supplies maximum protection without nuisance tripping.
Max.
(3)
(3)
Maximum protection device size is the highest rated device that supplies drive protection. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum.
Min.
(2)
Max.
(3)
Max.
(5)
(5)
Maximum allowable rating by US NEC. Exact size must be chosen for each installation.
Max.
(5)
Available Catalog Numbers
(9)
(9)
The AIC ratings of the Bulletin 140M Motor Protector may vary. See publication 140M-SG001B-EN-P.
600 Volt AC Input 20AE0P9 A 0.5 0.33 1.3 1.3 0.9 1.1 1.4 3 3 3 3.5 15 3 140M-C2E-B16 – – –
20AE1P7 A 1 0.75 1.9 2 1.7 2 2.6 3 6 3 6 15 3 140M-C2E-B25 140M-D8E-B25 – –
20AE2P7 A 2 1.5 3 3.1 2.7 3.6 4.8 4 6 4 10 15 7 140M-C2E-B40 140M-D8E-B40 – –
20AE3P9 B 3 2 4.4 4.5 3.9 4.3 5.9 6 8 6 15 15 7 140M-C2E-B63 140M-D8E-B63 – –
20AE6P1 B 5 3 7.5 7.8 6.1 6.7 9.2 10 12 10 20 20 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 –
20AE9P0 C 7.5 5 7.7 8 9 9.9 13.5 10 20 10 35 35 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 –
20AE011 C 10 7.5 9.8 10.1 11 13.5 18 15 20 15 40 40 15 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 –
20AE017 D 15 10 15.3 15.9 17 18.7 25.5 20 35 20 60 60 30 140M-C2E-C20 140M-D8E-C20 140M-F8E-C20 –
20AE022 D 20 15 20 20.8 22 25.5 34 25 45 25 80 80 30 140M-C2E-C25 140M-D8E-C25 140M-F8E-C25 140-CMN-2500
20AE027 D 25 20 24.8 25.7 27 33 44 35 60 35 100 100 50 – – 140M-F8E-C25 140-CMN-2500
20AE032 D 30 25 29.4 30.5 32 40.5 54 40 70 40 125 125 50 – – 140M-F8E-C32 140-CMN-4000
20AE041 E 40 30 37.6 39.1 41 48 64 50 90 50 150 150 100 – – 140M-F8E-C45 140-CMN-4000
20AE052 E 50 40 47.7 49.6 52 61.5 82 60 110 60 200 200 100 – – – 140-CMN-6300
