Rocky Mountain Element - Plastic Component Installation

11
3) Plastic Component Installation
3.1 Downtube Cable Port
1) Apply Loctite 243 (blue) to Counter Sunk
M5-0.8x16mm (1806009) Screw threads.
2) Pass M5-0.8x16mm Screws through
Downtube Cable Port (1807052)
and thread into front triangle.
Torque to snug (<1 Nm).
3.2 Head Tube Cable Ports
1) Apply Loctite 243 (blue) to Counter Sunk
M5-0.8x16mm (1806009) Screw threads.
2) Pass M5-0.8x16mm Screws through
Drive-Side (1087140) and Non-
Drive-Side (1097136) Head Tube
Cable Ports and thread into front
triangle.
Torque to snug (<1 Nm).
