Rocky Mountain Element - Bearing Removal

16
6) Bearing Removal
6.1 Main Pivot
1) Use a blind puller seated against the bearing inner races to remove main pivot bearings.
6.2 Top Link & Chain Stay
1) Align 6900 Bearing
Press against bearing
inner race (inboard for
link, outboard for chain
stay).
2) Pass bolt through 6900
Bearing Press, and thread into
6900 Bearing Cup.
3) Tighten bolt to
remove
bearing.
