Rocky Mountain Element - Frame Assembly

7
2) Frame Assembly
2.1 Chain Stay Installation
1) Grease outside of main pivot
bearing inner races, and outer
surface of Main Pivot Bolt
(1807045).
Apply Loctite 243 (blue) to female
threads on the drive-side of the
chain stay yoke.
2) Slide chain
stay over front
triangle main
pivot.
3) Install Main Pivot
Bolt.
Torque to 17 Nm.
