Roger Technology CTRL Instruction And Warnings For The Installer

EN
88
15 Safety input and command status (TEST mode)
;MXLRSGYVVIRXP]EGXMZIMRXIRXMSREPGSQQERHWTVIWWXLI8)78FYXXSRERHGLIGOXLIJSPPS[MRK
DISPLAY POSSIBLE CAUSE ACTION BY SOFTWARE PHYSICAL CORRECTIVE ACTION
U(rS)
MASTER barrier not moving. STOP
contact of MASTER barrier open
(message visible for SLAVE barrier). -
Check STOP button/contact on MAS-
TER controller.
Install a STOP button (NC) or jumper the
ST contact with the COM contact of the
MASTER controller.
EU
Detachable boom support system
enabled or not connected or incor-
rect connection.
Check the settings of parameter . Check the correct system connection
to the control unit.

Safety STOP contact open.
-
Check the STOP button/contact.
Install a STOP button (NC) or jumper the
ST contact with the COM contact.
Release device open.
-
AGILIK-KB-BI/004HP-BI/006-BI/008
Lock by turning the key two complete
turns clockwise.
Check that the microswitch contact is
connected correctly.
BIONIK4
Close the release lock cover and turn
the key.
Check that the microswitch contact is
connected correctly.
Barrier inspection hatch open.
-
Close the barrier inspection hatch.
Check connection to microswitch.

Sensing edge COS not connected or
incorrectly connected.
Set the parameter  if not used
or to disable.
If not used jumper contact COS with
contact COM.

Photocell FT not connected or incor-
rectly connected.
Set parameters  and  if
not used or to disable.
If not used jumper contact FT with con-
tact COM.
Check connection referring to relative
GSRRIGXMSRHMEKVEQƼKYVIW
SS
If occurs with no voluntary com-
mand, the contact may be faulty or
one of the buttons may be incorrectly
connected.
-
Check PP - COM contacts and connec-
tions to button.
&+
-
Check CH - COM contacts and connec-
tions to buttons.
DS
-
Check AP - COM contacts and connec-
tions to button.
SH
-
Check PED - COM contacts and connec-
tions to button.
2U
If occurs with no command, the con-
tact may be faulty or the timer may
be incorrectly connected.
-
Check contacts ORO - COM.
Do not jumper this contact if not used.
N.B: press TEST to exit TEST mode.
We recommend troubleshooting safety device and input status errors with “corrective action by software” only.
