Roland E-50 - Keyboard Parts List

E-50
Aug. 2006
15
14
KEYBOARD PARTS LIST
DO
DO
1
2
3
4
5
6
8
7
9
11
10
PARTS NAME
SPRING F/KEY 55 GR. No.118(23105270)
-
NATURAL KEY C5 DO
RE
MI
FA
SOL
LA
SI
DO(F)
NATURAL KEY D6
NATURAL KEY E7
NATURAL KEY F1
NATURAL KEY G2
NATURAL KEY A3
NATURAL KEY B4
NATURAL KEY C8
SHARP KEY
SCREW 2,9x10 TCTCPR TROP
12P RUBBER CONTACT ADI-LR13/12(25640210)
13P RUBBER CONTACT ADI-LR13/13(25640220)
LEFT CONT. PCB ASSY+RUBBER 32 KEY (26043130)
RIGHT CONT. PCB ASSY+RUBBER 29 KEY (26043120)
KEYBOARD SUPPORT 61 KEYS
UPPER GUIDE BUSHING
FELT FOR KEYBOARD ASSY
CODE RJA Num.
J2179116 61
J2579123 5
J2579124 5
J2579125 5
J2579126 5
J2579127 5
J2579128 5
J2579129 5
J2579130
1
22578318 25
J2289125 34
J3169110 4
J3169111 1
J2929105
J2929106
1
1
22818746 1
22158789 1
2235815101
1
N
O.
2
3
5
6
1
PM
SM
4
CONTACT BOARDS ARE COMPLETE WITH RUBBER CONTACTS
*
*
11
9
7
10
8
12P RUBBER CONTACT
12P RUBBER CONTACT
12P RUBBER CONTACT 12P RUBBER CONTACT 13P RUBBER CONTACT
8P 4P+
ASSEMBLY OF RUBBER CONTACT
