18
CASING Q.ty
# K2278104 RIGHT SPEAKER GRILL E-50/E-60 1
# K2278105 LEFT SPEAKER GRILL E-50/E-60 1
# K2018131 SOUNDPROOFED BOTTOM CBNT+BOX E-50 1
# K2028148 SILK.+VARN. LCD COVER E-50 1
# 7778203000 SILK.+VARN. TOP CABINET E-50 1
# K2198121 BLACK VARNISHED MUSIC REST E-50/E-60 1
22208320 MUSIC SCORE HOLDER 1
KNOB BUTTON
K2478418 ENCODER BLACK KNOB G-70 1
K2478439 BLACK KNOB+WHITE INSERT E-80 2
3249559701 SWITCH CAP 1
# K2478440 42-BUTTON GROUP (RIGHT COND.PAD) E50/60 1
# K2478441 36-BUTTON GROUP (LEFT CONDUCT.PAD)E50/60 1
# K2478442 4-BUTTON GROUP (CENTRAL COND.PAD) E50/60 2
SWITCH
J3129101 SWITCH SDKLA11000 SW1 on Power Switch B. 1
# J3139101 SWITCH SSAB110100 1
JACK, SOCKET
J3449104 DC SUPPLY SOCKET 2DC-0005G NL14007 JK5 on Audio B. 1
13449252 JACK SOCKET YKB 21-5006 JK11,JK12 on Card Protect B. 2
13449126 JACK SOCKET HLJ0520-01-010 JK2 on Audio B. 1
13449283 JACK SOCKET HLJ7101-01-3010 JK3,JK4,JK8 on Audio B. 3
13429697 5P DIN SOCKET TCS5350-01-4051 JK6,JK11 on Audio B. 2
01459945 USB SOCKET YKF45-0002 JK10 on Audio B. 1
DISPLAY UNIT
# J5039111 LCD SP14Q006-ZZA+TOUCH PANEL 1
DISK DRIVE UNIT
NNoottee :: J240910801 FLOPPY DISK DRIVER ALPS DF354H148G 1
BENDER UNIT
NNoottee :: K3278112 PITCH BENDER SW + CABLE (36)+1C. 1
SPEAKER
# K2418131 TWEETER SPEAKER 4 OHM E-50/E-60 2
# K2418130 WOOFER SPEAKER 4 OHM Z001401 2
KEYBOARD ASSY
J2589110 61-KEY TP/7BA+C(DR) KEYBOARD 65074700 1
NOTE: For details, refer to KEYBOARD PARTS LIST
PCB ASSY
# 7778201000 MAIN BOARD PCB ASSY E-50 1
# 7778103000 AUDIO PCB ASSY E-50/E-60 1
# 7778105000 RIGHT CONTROL PCB ASSY E-50/E-60 1
# 7778202000 LEFT CONTROL PCB ASSY E-50 1
# 7778106000 CENTER CONTROL PCB ASSY E-50/E-60 1
# 7778112000 VOLUME PCB ASSY E-50/E-60 1
# 7778108000 ENCODER ASSY E-50/E-60 1
# 7778109000 CARD PROTECT PCB ASSY E-50/E-60 1
# 7778110000 HEADPHONES PCB ASSY E-50/E-60 1
# 7778111000 POWER SWITCH PCB ASSY E-50/E-60 1
PARTS LIST
NOTE:
# The parts marked " # '' are new (Initial Parts).
A The parts marked " A '' are new (Initial Parts).for RES but already used by RJA
The parts marked have Safety - Related characteristics.
Use only listed parts for replacement.
<< EMI >> Component for EMC.
NNoottee :: Replacement should be made on a unit basis. No replacements available for individual parts.
Replacement only be a unit.
To Next Page
