Roland E-50 - Floppy Disk Drive Check

E-50
39
Protect Dis
Test OK
2DD Dis
Test OK
2HD Dis
Test OK
1.1 FLOPPY DISK Driver Check
c Insert a protected disk and check that the display shows a “marking” symbol near the writing Test Protect Dis
d Insert a DD disk and check that the display shows a “marking” symbol near the writing Test 2DD Dis
e Insert a DD disk and check that the display shows a “marking” symbol near the writing Test 2HD Dis
f At the end of the tests, touch the icon NEXT, to pass to the next test.
c d e
f
