E-50
45
1.15.4 Measurement of the PHONES exits
c Connect the headphones with the PHONES 1 exit of the E-50
d Press the icons MID and L (the MUTE must be OFF)
c d
e Check that the sound is clean and comes from the LEFT loudspeaker of the headphones only.
f Press the icon R
g Check that the sound is clean and comes from the RIGHT loudspeaker of the headphones only.
h Press the icons LR
