113
Settings for the Entire FANTOM
Keyboard Settings (KEYBOARD)
Parameter Value Explanation
Keyboard Velocity
Specifies the velocity transmitted when a key is played.
REAL
The transmitted velocity value will
correspond to the force with which
you strike the key.
1–127
The transmitted velocity value will
be fixed, regardless of the force with
which you strike the key.
Keyboard Velocity Curve
LIGHT
The keyboard will have a
lighterfeeling touch. Since you’ll be
able to reach fortissimo (ff ) without
having to play as strongly as with
the “MEDIUM” setting, the keyboard
will feel lighter. This setting makes it
easier for people with reduced finger
strength to play the keyboard.
MEDIUM
This is the standard keyboard touch
setting.
HEAVY
The key will have a heavier-feeling
touch. Since you’ll need to play more
strongly than with the “MEDIUM”
setting in order to reach fortissimo
(ff), the keyboard will feel heavier. This
setting allows you to use your playing
dynamics to add more expression to
your performances.
Keyboard Velocity Curve
Offset
-10–+9
Adjusts the keyboard velocity curve.
Lower values make the keyboard
feel lighter. Higher values make the
keyboard feel heavier.
Hi-Res Velocity Out OFF, ON
Specifies whether high-resolution
velocity data is transmitted.
Aftertouch Sens 0–100
Specifies the aftertouch sensitivity.
Higher settings make it easier to apply
aftertouch. Normally you will leave
this at 100.
Arpeggio
Arpeggio Trigger
Quantize
Specifies how arpeggios will be triggered.
OFF
The arpeggio starts the moment you
play the keyboard.
BEAT
If you play the keyboard while the
sequencer or a rhythm pattern is
playing, the arpeggio automatically
starts at the beginning of the beat.
MEAS
If you play the keyboard while the
sequencer or a rhythm pattern is
playing, the arpeggio automatically
starts at the beginning of the
measure.
Arpeggio Switch Mode
OFF/ON
The ARPEGGIO screen does not
appear when you operate the
[ARPEGGIO] button to change from
OFF to ON.
OFF/ON & ARP
SCREEN
The ARPEGGIO screen appears when
you operate the [ARPEGGIO] button to
change from OFF to ON.
Chord Memory Switch
Mode
OFF/ON
The CHORD MEMORY screen does not
appear when you operate the [CHORD
MEMORY] button to change from OFF
to ON.
OFF/ON & CHD
SCREEN
The CHORD MEMORY screen appears
when you operate the [CHORD
MEMORY] button to change from OFF
to ON.
Pedal Settings (PEDAL)
Parameter Value Explanation
Pedal Assign Source SYS, SCENE
Specifies whether the functions
controlled by pedals connected to
the PEDAL CTRL 1, 2/L, 3/C jack are
determined by the system settings
(SYS) or by the settings of the scene
(SCENE).
Control Pedal
Pedal1–3 Polarity
STANDARD,
REVERSE
Selects the polarity of the pedal
connected to the PEDAL CTRL 1, CTRL
2/L, and CTRL 3/C jacks.
Depending on the model of pedal,
the result of depressing or releasing
the pedal might be the opposite of
what you expect. If so, choose the
“REVERSE” setting. If you’re using a
Roland pedal (that has no polarity
switch), choose the “STANDARD”
setting.
Pedal1–3 Assign
Specify the functions that are controlled by pedals
connected to the PEDAL CTRL 1, 2/L, 3/C jacks.
OFF No function is assigned.
CC01–31,
33–95
Controller number 1–31, 33–95
BEND DOWN
The same effect as moving the pitch
bend lever to the left.
BEND UP
The same effect as moving the pitch
bend lever to the right.
AFT Aftertouch
START/STOP Start/stop the sequencer.
TAP TEMPO
The same effect as pressing the panel
[TAP] button.
SCENE DOWN
Switch the scene to the previous
number. When using a scene chain,
switch to the previous number in the
chain set.
SCENE UP
Switch the scene to the next number.
When using a scene chain, switch to
the next number in the chain set.
OCT DOWN
The same effect as pressing the panel
OCTAVE [DOWN] button.
OCT UP
The same effect as pressing the panel
OCTAVE [UP] button.
ARPEGGIO SW
The same effect as pressing the panel
[ARPEGGIO] button.
CHORD MEM
SW
The same effect as pressing the panel
[CHORD MEMORY] button.
DEC
The same effect as pressing the panel
[DEC] button.
INC
The same effect as pressing the panel
[INC] button.
Pedal1–3 Range Min 0–127
Specify the lower limit value for the
range of the assigned function.
Pedal1–3 Range Max 0–127
Specify the upper limit value for the
range of the assigned function.
Hold Pedal
Hold Pedal Polarity
STANDARD,
REVERSE
Selects the polarity of the pedal
connected to the PEDAL HOLD/R jack.
Depending on the model of pedal,
the result of depressing or releasing
the pedal might be the opposite of
what you expect. If so, choose the
“REVERSE” setting. If you’re using a
Roland pedal (that has no polarity
switch), choose the “STANDARD”
setting.
Continuous Hold Pedal OFF, ON
If this is ON, the PEDAL HOLD/R jack
will support half-pedaling. If half-
pedaling is enabled, you can connect
a damper pedal (such as the DP-10;
available separately) and use the
pedal to control subtle nuances of the
piano sounds you play.
To Next Page
