24
How to Use
Recording Microphone or Guitar Sound (MIC/GUITAR)
When you set the recording mode to “MIC/GUITAR, you can record microphone and guitar sounds
on each track individually.
Computer
Amplied speakersHeadphones
Set the input port for the track in the software.
When using SONAR, set as follows:
When recording the microphone sound: Left IN
(TRI-CAPTURE)
When recording the guitar sound: Right IN (TRI-
CAPTURE)
When connecting
a condenser
microphone, set the
[PHANTOM] button to
“48V.
Make sure that the
[PHANTOM] button
is set to “OFF” when
connecting a dynamic
microphone that does
not require phantom
power (p. 10).
When connecting a guitar or
bass, set the [Hi-Z] button to
“ON” (p. 10).
Rear panel
Use the [INPUT 1 (MIC)] and [INPUT 2 (GUITAR)] knobs to adjust the input level so that the PEAK
indicator does not light.
