Main Specications
USB Audio Interface: Roland TRI-CAPTURE UA-33
Number of Audio Record/
Playback Channels
Record
1 pair of stereo
* All inputs are mixed to 1 pair stereo on ALL
INPUTS and LOOP BACK mode.
Playback
1 pair of stereo
Full duplex (Except 96 kHz)
Signal Processing 24 bits (linear)
Sampling Frequency 96 kHz, 48 kHz, 44.1 kHz
Nominal Input Level
INPUT1 (MIC) jack -60 to -30 dBu
INPUT2 (GUITAR) jack -25 dBu
INPUT3 (AUX) jacks -10 dBu
Nominal Output Level OUTPUT jacks +4 dBu (Balance)
Residual Noise Level
-93 dBu typ.
(input terminated with 1 k ohms, Input Monitor: OFF, IHF-A, typ.)
Dynamic Range 100 dB typ.
Interface USB
Rec Mode
MIC/GUITAR
ALL INPUTS
LOOP BACK (Except 96 kHz)
Controller
[INPUT1 (MIC)], [INPUT2 (GUITAR)], [INPUT3 (AUX)] knob
[PHONES] knob
[PHANTOM] button
[Hi-Z] button
[REC MODE] button
[OUTPUT MUTE] button
[INPUT MONITOR] button
[SAMPLE RATE] switch
[MODE] switch
Indicator
PEAK indicators
SIG indicators
Connectors
INPUT1 (MIC) Jack (XLR type, balanced, phantom power DC 48 V, 10 mA)
* 1/4-inch phone type and plug-in powered microphone cannot connected
INPUT2 (GUITAR) jack (1/4-inch phone type)
INPUT3 (AUX) jacks(L, R) (RCA phono type)
OUTPUT jacks (L, R) (1/4-inch TRS phone type (balanced))
PHONES jack (stereo 1/4-inch phone type)
USB connector (USB Type B)
Power Supply Supplied from the computer via USB
Current Draw 450 mA
