11
KIT EDIT
SETTING
MEMO
Use the cursor [
] [ ] buttons to move to settings such as SEND/FILTER and LIMITER.
PAD SEND LEVEL/FILTER
Here you can specify how the overhead applies for each pad.
Parameter Value Explanation
Pad Filter Select
BYPASS, 1–4
Overhead input lter selection for each pad
BYPASS The input lter is not used; the sound is sent directly to the overheads.
1–4 The sound is sent to the specied input lter.
Pad Send Level
-INF–+6.0dB Depth of overhead for each pad
[F5] button (H & R)
H&R OFF, H&R ON Species whether head and rim of instruments are selected as a set (ON) or independently (OFF).
PRE LIMITER
This is a limiter/compressor applied before the sound is input to the overhead.
Parameter Value Explanation
Pre Comp Switch
OFF, ON Turns the pre limiter on/o.
Gain
-24.0–+24.0dB Output volume of the pre limiter
Threshold
-60–0dB Volume level at which compression begins
Ratio
1:1–100:1 Compression ratio
Knee
HARD, SOFT1–3 Attack of the sound at the moment compression is applied
Attack
0.1–100mSec Time from when the volume goes up the threshold level until the compressor eect applies
Release
10–1000mSec
Time from when the volume falls below the threshold level until the compressor eect no longer
applies
MIC SETTING
These are the overhead mic settings.
Parameter Value Explanation
Mic Type
TYPE1–4 Type of mic
Mic Width
0–4 Distance between mics
Distance
0–6 Distance between the mics and the performer
Output Width
DEFAULT, WIDE+1–+6 Sense of space for the overhead sound
