KIT EDIT
SUB INSTRUMENT
You can layer the main instrument with a sub instrument so that they are heard together. You can also switch between two instruments according
to the force of your strike, or vary the balance between them.
Parameter Value Explanation
[F1] button (OFF, SUB ON)
OFF, SUB ON Turns the sub-instrument on/o.
[F2] button (SUB INST tab)
SUB INST
001–728 (preset)
U001–U500 (user sample)
Sub-instrument number
& Refer to “Instrument List” (p. 50).
Layer Type
These parameters specify how the sub instrument will be sounded.
MIX
Playing
Dynamics
Volume
The main instrument (A) and sub instrument (B) always sound together as
a layer.
FADE1
Volume
Playing
Dynamics
The sub instrument (B) is added as a layer only if the strike is stronger than
“Fade Point.”
FADE2, FADE3
Volume
Playing
Dynamics
If the strike is stronger than “Fade Point,” the sub instrument (B) is added as a
layer according to the strength of that strike.
FADE2:
At 127 or higher, the main instrument (A) and sub instrument (B) are the
same volume.
FADE3:
At 127+32, the main instrument (A) and sub instrument (B) are the same
volume (for pads that support digital connection).
SWITCH
Volume
Playing
Dynamics
Strikes weaker than “Fade Point” sound the main instrument (A), and strikes
stronger than “Fade Point” switch to sound the sub instrument (B).
Fade Point
1–127+32
Species the force of the strike at which the sub instrument begins to be sounded.
If this is “1,” the sub instrument is sounded by a strike of any force.
If this is “127” (“127+32” for a pad that supports digital connection), the sub instrument is sounded
only by the strongest strike.
* This is not available if Layer Type is “MIX.”
Sub Volume
-INF–+6.0dB Volume of the sub-instrument
[F3] button (EDIT tab)
– For details on the parameters that can be edited, refer to “INSTRUMENT” (p. 4).
