Roland V-Synth Service Notes

14
V-SYNTH
01906667 MNR14 EOAB J 100 RESISTOR-ARRY RA17,RA2,RA4,RA3,RA6,RA18,RA23,RA2
4 on Sub board
8
13749817T0 SR25TRE 682 J CARBON RESISTOR R24,R18,R11,R3 on Jack Board 4
# 13749851T0 CARBON RESISTOR SR25TRE
184 J
CARBON RESISTOR R21,R7 on Jack Board 2
13749807T0 SR25TRE 272 J CARBON RESISTOR R17,R10,R23,R29,R6,R2 on Jack Board 6
13749203T0 1/2W 47 OHM CARBON RESISTOR R4,R5,R19,R20 on Jack Board 4
13749773T0 SR25TRE 101 J CARBON RESISTOR R35,R14 on Jack Board ,R4,R6,R2,R1,R5,R3
on Panel-R Board ,R22,R19 on Pad
Board,R125,R128 on Lcd Board
2
+6
+2
+2
13749785T0 SR25TRE 331 J CARBON RESISTOR R27,R37,R43,R47 on Jack Board 4
13749793T0 SR25TRE 681 J 680 OHM 1/4W CARBON RESISTOR R26,R46,R42,R36 on Jack Board 4
13749797T0 SR25TRE 102 J CARBON RESISTOR R13,R22,R34,R8 on Jack Board 4
13749809T0 SR25TRE 332 J 1/6W CARBON RESISTOR R45,R41,R49,R31 on Jack Board 4
13749821T0 SR25TRE 103 J CARBON RESISTOR R30,R48,R44,R40 on Jack Board 4
+2
13749829T0 SR25TRE 223 J CARBON RESISTOR R16,R51,R50,R38,R15,R39 on Jack Board 6
13749839T0 SR25TRE 563 J CARBON RESISTOR R32,R9 on Jack Board 2
13749869T0 SR25TRE 105 J CARBON RESISTOR R1,R28 on Jack Board 2
03012990 MCR50 JZH J 2R2 CARBON RESISTOR R29,R27,R23 on Panel-L board 3
00566989 RPC05T 560 J MTL.FILM RESISTOR R71 on Panel-L board 1
00567389 RPC05T 563 J MTL.FILM RESISTOR R8 on Panel-L board 1
00567089 RPC05T 331 J MTL.FILM RESISTOR R17 on Panel-L board 1
00567212 RPC05T 332 J MTL.FILM RESISTOR R19,R2 on Panel-L board 2
00567234 RPC05T 392 J MTL.FILM RESISTOR R21,R22,R26,R28,R63 on Panel-L board 5
00567256 RPC05T 562 J MTL.FILM RESISTOR R20 on Panel-L board 1
00567267 RPC05T 682 J MTL.FILM RESISTOR R11 on Panel-L board 1
00904701 RR1220P-302-D 3KOHM (D-
RANK)
MTL.FILM RESISTOR R57,R45 on Panel-L board 2
15419728 RR1220P-562-D 5.6K MTL.FILM RESISTOR R41,R50 on Panel-L board 2
13749767T0 SR25TRE 560J CARBON RESISTOR R7,R8 on Panel-R Board 2
13749791T0 SR25TRE 561 J CARBON RESISTOR R24,R25 on Pad Board,R140 on Lcd Board 1
+2
13749813T0 SR25TRE 472 J CARBON RESISTOR R142 on Lcd Board 1
13749845T0 SR25TRE 104 J 1/4W CARBON RESISTOR R126,R129 on Lcd Board 2
15229941 10KD-5 THERMISTOR RESISTOR R141 on Lcd Board 1
13749853T0 SR25TRE 224 J 1/3W 1/4W CARBON RESISTOR R23,R20 on Pad Board 2
RESISTOR
POTENTIOMETER
02676878 EVUE20E15B14 9M/M ROTARY POTENTIOM-
ETER
VR1 on Sub board 1
02891878 RK09D1130 10KB 9M/M ROTARY POTENTIOM-
ETER
VR3,VR2 on Panel-L
board,VR16,VR15,VR8,VR7 on Panel-R
Board
2
+4
# 03122145 RK09D1130C3W 9M/M ROTARY POTENTIOM-
ETER
VR1 on Panel-L
board,VR19,VR3,VR20,VR18,VR17,VR2,VR
14,VR12,VR11,VR10,VR9,VR4,VR13,VR5,V
R1,VR6 on Panel-R Board
1
+16
# 03122090 EVJ Y15 F01 A15 12M/M ROTARY POTENTI-
OMETER
VR5 on Panel-L board 1
# 03122089 EWA NJO C15 B14 30M/M SLIDE POTENTIOME-
TER
VR4 on Panel-L board 1
# 03122123 EWA NKE C15 B14 30M/M SLIDE POTENTIOME-
TER
VR21,VR22,VR24,VR23 on Panel-R Board 4
CAPACITOR
00567823 GRM39B102K50PT CERAMIC CAPACITOR C662,C663,C69 on Main board 3
00567945 GRM39B103K50PT CERAMIC CAPACITOR C583,C573,C575,C572 on Main board 4
00567978 GRM39F104Z25PT CERAMIC CAPACITOR C532,C511,C512,C555,C513,C522,C525,C52
8,C554,C552,C534,C551,C510,C549,C544,C5
33,C122,C543,C540,C553,C142,C132,C133,C
13,C12,C11
172
,C135,C136,C138,C505,C140,C509,C502,C12
4,C5,C556,C503,C504,C127,C123,C506,C507
,C139,C670,C600,C574,C634,C620,C635,C63
6,C641,C557,C643,C598,C671,C672,C673,C6
82,C683,C690,C691,C692,C43,C121,C642,C5
70,C558,C559,C10,C562,C563,C565,C566,C6
02,C569,C597,C571,C9
,C579,C581,C589,C590,C591,C594,C595,C59
6,C568,C48,C37,C60,C39,C40,C41,C22,C14,
C44,C47,C36,C49,C50,C51,C52,C53,C54,C5
5,C57,C58,C46,C19,C25,C26,C27,C28,C29,C
21,C20,C38,C31,C35,C18,C17,C16,C32,C33,
C15,C45,C120,C34,C30,C109,C98,C99,C100
,C101,C102,C103,C104,C97,C106,C111,C110
,C62,C112,C42,C114,C115,C116,C117,C118,
C119,C105,C79,C113,C66,C67,C70,C71,C72,
C96,C78,C81,C82,C83,C90,C91,C64,C92,C6
3,C93,C94,C95,C73 on Main board
01349312 GRM39F105Z10PT CERAMIC CAPACITOR C535,C653,C689,C688 on Main board 4
01672412 GRM39CH150J50PT CERAMIC CAPACITOR C592,C593,C520,C519 on Main board 4

Roland V-Synth Specifications

General

Arpeggiator	Yes
Velocity Sensitivity	Yes
Aftertouch	Yes
Vocoder	Yes
USB	No
Keyboard	61 keys (velocity and aftertouch sensitive)
Effects	Chorus, Delay, Reverb, Distortion, Flanger, Phaser
Sampling	Yes
Display	320x240 pixel color LCD
MIDI	In/Out/Thru
Type	Synthesizer
LFO	Yes
Storage	SmartMedia card
Outputs	Stereo
Headphones	Yes
Power Supply	AC
Inputs	Stereo Line, Microphone
Audio Inputs	Stereo Line, Mic
