15
Mar.2003
01675167 GRM39CH100D50PT CERAMIC CAPACITOR C587,C585,C576,C586 on Main board 4
01675190 GRM39CH220J50PT CERAMIC CAPACITOR C560,C75,C561 on Main board 3
01675201 GRM39CH270J50PT CERAMIC CAPACITOR C76 on Main board 1
01675234 GRM39CH470J50PT CERAMIC CAPACITOR C86,C84,C85 on Main board 3
01675312 GRM39CH221J50PT CERAMIC CAPACITOR C141 on Main board 1
01898423 ECHU1H222JX5 POLYEST. CAPACITOR C609,C606 on Main board 2
01898434 ECHU1H101JX5 POLYEST. CAPACITOR C616,C632,C629,C625,C639,C617,C613,C60
7,C601,C619 on Main board
10
01906612 ECHU1H122JX5 POLYEST. CAPACITOR C618,C614,C626,C633 on Main board 4
# 03120901 ECHU1C822JX5 POLYEST. CAPACITOR C577 on Main board 1
01900834 RA2-16V101M-T2 CHEMICAL CAPACITOR C12,C33,C16,C19,C23,C29 on Jack
Board,C627,C630,C527,C524 on Main
board,C44,C67,C66,C51,C49,C45,C43,C38,C
36,C30,C29,C47 on Panel-L board
4
+6
+1
2
01909690 RA2-16V471MC-T2 CHEMICAL CAPACITOR C526 on Main board ,C114,C126,C121 on
Sub board
1
+3
02344990 RV2-50V4R7M-R CHEMICAL CAPACITOR C647 on Main board 1
02345101 RV2-16V100M-R CHEMICAL CAPACITOR C501,C134,C545,C584,C61 on Main board 5
02345134 RV2-16V470M-R CHEMICAL CAPACITOR C608,C605 on Main board 2
02345145 RV2-16V101M-R CHEMICAL CAPACITOR C107,C89,C1,C108,C125,C564,C508,C536 on
Main board
8
# 03015378 RV-25V221MG10-R CHEMICAL CAPACITOR C646,C548,C645 on Main board 3
02897278 SKF-0J106MZ4-RP TANTALUM CAPACITOR C7,C664,C3,C2,C622,C59,C624,C637,C656,
C640,C612,C56,C65,C68,C567,C604,C610,C
655,C8 on Main board
19
# 02904434 SK8-0J476MZ4-RA TANTALUM CAPACITOR C24,C23 on Main board 2
# 03015345 SK2-1A476MZ4-RD0 TANTALUM CAPACITOR C88,C87 on Main board 2
# 03015356 SK5-1A157MZ4-RD0 TANTALUM CAPACITOR C530,C529 on Main board 2
# 03015367 SKF-1C474MZ4-RP TANTALUM CAPACITOR C580 on Main board 1
01674701 ECJ1VF1E104Z 0.1UF/16VK CERAMIC CAPACITOR C63,C65,C64,C52,C50,C12,C48,C5,C15,C17,
C26,C27,C11,C8,C3,C46,C16 on Panel-L
board
,C113,C79,C80,C89,C106,C108,C109,C112,C
117,C118,C75,C111,C72,C71,C70,C63,C61,C
59,C119,C25,C57,C10,C5,C4,C3,C44,C26 on
Sub board
27
+1
7
01674334 ECUV1H101JCV CERAMIC CAPACITOR C103,C97,C96,C98,C99,C100,C102,C104,C1
05,C128,C101,C94,C95,C91,C90,C88,C87,C8
6,C85,C84,C83,C40,C129,C93,C92 on Sub
board
25
01674212 ECUV1H220JCV CERAMIC CAPACITOR C21,C22 on Sub board 2
01674434 ECUV1H561JCV CERAMIC CAPACITOR C122 on Sub board 1
01674612 ECJ1VB1H103K CERAMIC CAPACITOR C68,C73,C67,C60,C18,C17,C16,C14,C13,C1
2,C11,C7,C2,C15,C74 on Sub board
15
01674712 ECJ1VF1A105Z CERAMIC CAPACITOR C58 on Sub board 1
01674190 ECUV1H150JCV CERAMIC CAPACITOR C50,C27,C32,C49,C48,C47,C28,C29,C30,C3
1,C51,C41,C45,C52,C43,C33,C42,C46,C39,C
38,C37,C36,C35,C34 on Sub board
24
01902867 RA2-25V101M-T2 CHEMICAL CAPACITOR C125,C127,C9,C64,C76,C77,C78 on Sub
board
7
# 03121023 RA2-35V220MC-T2 CHEMICAL CAPACITOR C120 on Sub board 1
13519534 DD104-63B102K50 50VK 1000PF CERAMIC CAPACITOR C3,C10,C18,C20,C24,C13 on Jack Board 6
13519641 DD308-959F104Z50 CERAMIC CAPACITOR C40,C30,C41,C32,C38,C34,C28 on Jack
Board
,C20,C24,C23,C21,C19,C25,C22,C26,C27,C2
8,C29,C18,C31,C7,C32,C33,C30,C2,C11,C1,
C17,C3,C10,C12,C13,C14,C15,C16 on Panel-
R Board ,C44,C43 on Inverter Board
,C20,C23 on Pad Board,C103,C106 on Lcd
Board
7
+2
8
+2
+2
+2
13519661 DD104-989SL150J50 CERAMIC CAPACITOR C14,C4 on Jack Board 2
13519671 DD104-989SL101J50 100PF 50VK CERAMIC CAPACITOR C9,C2,C11,C5 on Jack Board ,C101,C102
on Lcd Board
4
+2
01893656 ROS-16V101M-T2 CHEMICAL CAPACITOR C15,C6 on Jack Board 2
01454889 RA2-16V470MT2 470UF/16V CHEMICAL CAPACITOR C27,C31,C36,C35 on Jack Board 4
02014890 RA2-16V221MT2 CHEMICAL CAPACITOR C8,C1 on Jack Board 2
00568456 ECJ1VF1C474Z CERAMIC CAPACITOR C2 on Panel-L board 1
01674167 ECUV1H100DCV CERAMIC CAPACITOR C33,C40 on Panel-L board 2
01674234 ECUV1H330JCV CERAMIC CAPACITOR C1 on Panel-L board 1
01674389 ECUV1H221JCV CERAMIC CAPACITOR C10 on Panel-L board 1
01674556 ECJ1VB1H472K CERAMIC CAPACITOR C4,C7 on Panel-L board 2
01674667 ECJ1VF1H333Z CERAMIC CAPACITOR C62 on Panel-L board 1
02129534 ECJ1VB1H102K CERAMIC CAPACITOR C9 on Panel-L board 1
# 03121590 RC3-6V221M-T2 CHEMICAL CAPACITOR C20,C21,C22 on Panel-L board 3
# 03121612 RC3-25V-220M-T2 CHEMICAL CAPACITOR C25,C14,C18,C23,C13,C24 on Panel-L board 6
# 03121623 RC3-25V100M-T2 CHEMICAL CAPACITOR C9,C8 on Panel-R Board 2
01900823 RA2-16V100M-T2 CHEMICAL CAPACITOR C21,C22 on Pad Board,C104,C105 on Lcd
Board
2
+2
02014923 RA2-35V470MT2 CHEMICAL CAPACITOR C113 on Lcd Board 1
01902590 RA2-6V101MC-T2 CHEMICAL CAPACITOR C42 on Inverter Board 1
CAPACITOR
INDUCTOR, COIL, FILTER
# 02900923 CDRH4D28-6R8 CHOKE COIL L1 on Main board 1
# 02900934 CDRH4D28-4R7 CHOKE COIL L511 on Main board 1
