16
V-SYNTH
# 02900945 CR75-220KC CHOKE COIL L2 on Main board 1
# 02900956 CR75-100KC CHOKE COIL L512 on Main board 1
01909645 EXCML16A270U FERRITE-BEAD L505,L501 on Main board 2
02238212 N2012ZPS121T50 FERRITE-BEAD L520 on Main board 1
01783590 BLM11B601SPT FERRITE-BEAD L522,L524,L525 on Main board 3
01349256 BLM11A601SPT FERRITE-BEAD L502,L513,L510,L509,L508,L507,L503,L514,
L504,L506,L532,L516,L517,L518,L519,L521,
L526,L515,L527,L528,L529,L531,L530 on
Main board
23
01672889 SBC3-221-681 CHOKE COIL L55 on Sub board 1
00903167 N2012Z601T02 (CHIP) FERRITE-BEAD L40,L66,L56,L67,L39,L30,L29,L28,L18,L17,L
16,L9,L8,L57,L58 on Sub board
15
01565578 N1608Z601T01 FERRITE-BEAD L68 on Sub board 21
02678467 SS11V-10062 LINE-FILTER COIL FL1 on Inverter Board 1
INDUCTOR, COIL, FILTER
CRYSTAL, RESONATOR
00901912 MA-406 24.576MHZ TE24 CRYSTAL X502 on Main board 1
01340745 MA-406 12MHZ CRYSTAL X501 on Main board 1
# 02896234 MA-406 22.1667MHZ CRYSTAL X1 on Main board 1
02672401 SG-8002JC 67.7376MHZ PC CRYSTAL X3 on Main board 1
00894023 MA-406 20.000MHZ TE24 CRYSTAL X1 on Sub board 1
ENCODER
# 03122134 EC12E2420802 ROTARY ENCODER EN1 on Panel-R Board 1
CONNECTOR
# 02896267 JC21EJ2-BRN20 CONNECTOR CN506 on Main board 1
02455412 S8B-PH-SM3-TB CONNECTOR CN509,CN511 on Main board 2
# 03120867 S12B-PH-SM3-TB CONNECTOR CN512 on Main board 1
02902823 B12B-PH-SM3-TB CONNECTOR CN501 on Main board 1
# 13369757 S7B-XH-A SIDE JST CONNECTOR CN502,CN503 on Main board 2
01908656 18FE-BT-VK-N CONNECTOR CN4 on Sub board 1
01908645 16FE-BT-VK-N CONNECTOR CN3 on Sub board 1
13369504 B8B-PH-K-S JST CONNECTOR CN1,CN6 on Panel-L board ,CN9,CN7,CN1
on Sub board ,CN12 on Pad Board
3
+2
+1
13369541 B10B-PH-K-S JST CONNECTOR CN2 on Panel-L board,CN1 on Panel-R
Board,CN12,CN10,CN6 on Sub board
,CN22 on Lcd Board
3
+1
+1
+1
13369562 B15B-PH-K-S JST CONNECTOR CN3 on Panel-L board,CN2 on Panel-R
Board,CN11,CN14 on Sub board
2
+1
+1
13369564 B12B-PH-K-S JST CONNECTOR CN4 on Panel-L board,CN3 on Panel-R
Board,CN13 on Sub board ,CN16 on Lcd
Board
1
+1
+1
+1
13369567 B4B-PH-K-S JST (4P) CONNECTOR CN5 on Sub board 1
13369592 B7B-XH-A(7P) JST CONNECTOR CN8 on Sub board,CN19,CN18 on Inverter
Board
1
+2
13369563 B14B-PH-K-S JST CONNECTOR CN1 on Jack Board ,CN5 on Panel-L board 1
+1
13369566 B6B-PH-K-S JST(6P) CONNECTOR CN2 on Jack Board ,CN7 on Panel-L board 1
+1
# 03122156 52030-0410 CONNECTOR CN23 on Lcd Board 1
01909601 12FE-BT-VK-N CONNECTOR CN17 on Lcd Board 1
02673145 B2(4-2.3)B-XH-A CONNECTOR CN27 on Inverter Board ,CN29,CN28 on
Lcd Board
2
+1
# 03122167 SLP8S-5 CONNECTOR CN13 on Pad Board 1
WIRING, CABLE
01450512 WIRING POWER CN26 on Inlet to CN1 on Power Suply Unit 1
02342056 WIRING 4X400-P2.0-PHR-PHR-F CN5 on Sub to CN1 on Bender Unit 1
02343234 WIRING 6X150-P2.0-PHR-PHR-F CN7 on Panel-L to CN2 on Jack 1
02343545 WIRING 8X150-P2.0-PHR-PHR-F CN1 on Panel-L to CN7 on Sub 1
02343567 WIRING 8X250-P2.0-PHR-PHR-F CN2 on Pad to CN9 on Sub 1
# 02343601 WIRING 8X450-P2.0-PHR-PHR-F CN509 on Main to CN1 on Sub 1
02343612 WIRING 8X500-P2.0-PHR-PHR-F CN6 on Panel-L to CN511 on Main 1
02343823 WIRING 10X200-P2.0-PHR-PHR-F CN2 on Panel-L to CN12 on Sub/CN22 on
Lcd to CN6 on Sub
2
02343856 WIRING 10X350-P2.0-PHR-PHR-F CN1 on Panel-R to CN10 on Sub 1
# 02344045 WIRING 12X300-P2.0-PHR-PHR-F CN3 on Panel-R to CN13 on Sub 1
# 02344056 WIRING 12X350-P2.0-PHR-PHR-F CN501 on Main to CN16 on Lcd 1
# 02344089 WIRING 12X500-P2.0-PHR-PHR-F CN511 on Main to CN4 on Panel-L 1
# 02344134 WIRING 14X150-P2.0-PHR-PHR-F CN5 on Panel-L to CN1 on Jack 1
02344289 WIRING 15X200-P2.0-PHR-PHR-F CN3 on Panel-L to CN11 on Sub 1
# 02344312 WIRING 15X350-P2.0-PHR-PHR-F CN2 on Panel-R to CN14 on Sub 1
02564356 WIRING 7X470-P2.5-XHP-XHP-F CN503 on Main to CN8 on Sub 1
02679390 WIRING 7X150-P2.5-XHP-XHP-F CN502 on Main to CN19 on Inverter 1
