17
Mar.2003
02679412 WIRING WIRING W2 CN18 on Inverter to CN2 on Power Suply
Unit
1
02566167 BAN CARD BNCD-P=1.25-K-18-450 CN4 on Sub to Keyboard Unit 1
# 03121534 BAN CARD BNCD-P=1.25-K-16-450 CN3 on Sub to Keyboard Unit 1
WIRING, CABLE
TRANSFORMER
02019478 (7KQ5) 19832A PULSE TRANS T501 on Main board 1
02457412 DHE1105-5VB INVERTOR MODULE MOD1 on Inverter Board 1
PICKUP, SENSOR
# 72230189 XY-PAD ASSY 1
SCREW
40010334 SCREW 4X8 BINDING BZC 1
40454045 SCREW 3X8 FLAT TAPTITEB NI FLANGE
SOCKET
8
40011067 SCREW 3X8 BINDING TAPTITE B FE ZC 22
40011123 SCREW 4X8 BINDING TAPTITE B BZC 27
40011056 SCREW 3X6 BINDING TAPTITE B ZC 44
40239734 SCREW 3X6 VWH B-TIGHT ZC 8
40011312 SCREW 3X8 BINDING TAPTITE P BZC 29
40012501 SCREW M4X12 BINDING TAPTITE P FE BZC 1
40012790 SCREW 3X8 FLAT TAPTITE P BZC 8
40011490 SCREW M3X6 PAN MACHINE W/SW BZC 14
40011745 HEX NUT M4 SPRING NUT FE ZC 1
PACKING
# 03128712 MANUAL PAD 1
# 03128701 CENTER PAD UPPER 1
# 03128690 CENTER PAD LOWER 1
# 03128689 SIDE PAD R 1
# 03128678 SIDE PAD L 1
# 03017845 PACKING CASE 1
MISCELLANEOUS
12359139 RUBBER FOOT FF-018 BLK 4
40122812 ACETATE TAPE NITTO NO.5 BLK W15MM 30M 20
01455523 CORD BUSHING EDS-1717U 1
01905445 CORD BUSHING WS-1NS 3
02673945 STAY BENDER 1
40017356 COATING CLIP CS-4 1
ACCESSORIES (STANDARD)
02670401 AC CORD SET 100V YA-101/YP-3N/YC-13 1
00894378 AC CORD SET 120V SP301+IS14 SJT18/3 1
23495124 AC CORD SET 240VA SC-144-JO1 ES303-
10HMA
1
00907001 AC CORD SET 240VE KP-610 GTTBS-3 KS-31A 1
# 03129034 CD-ROM DRIVER 1.00 1
+1
# 72014989 OWNER’S MANUAL JAPANESE 1
# 72232512 OWNER’S MANUAL ENGLISH 1
40232334 WARRANTY CARD MOCHIKOMI JAPAN ONLY 1
# 03120712 CARD PROTECTOR 1
To Next Page
