About the Power Supply
11
About Securing the Power Cord
You can use either of the two methods described below to secure the power cord in place. Doing
this can prevent inadvertent disruption of power to your unit (should the plug be pulled out
accidentally) and avoid applying undue stress to the DC IN jack.
Securing using the cord hook
You can secure the cord in place as shown below.
Cord hook
Securing using the holes in the top/bottom panel
You can secure the cord using the holes in the top or bottom panel, as shown below.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Roland VC-1-SC and is the answer not in the manual?

Roland VC-1-SC Specifications

General IconGeneral
Quantity1
Cables includedAC
AC adapter includedYes
Video inSDI, HDMI, VGA
Video outSDI, HDMI
Output interfaceSDI/HDMI
Operating voltage9 V
Maximum video resolution1920 x 1200 pixels
Analog signal format systemNTSC, PAL
Supported resolutions640x480/60/72/75/85Hz, 800x600/56/60/72/75/85Hz, 1024x768/60/70/75/85Hz, 1280x720/60Hz, 1280x768/60/75/85/Hz, 1360x768/60Hz, 1152x864/75Hz, 1400x900/60/75/85Hz, 1280x960/60/85Hz, 1280x1024/60/75/85Hz, 1400x1050/60/75Hz, 1680x1050/60Hz, 1600x1200/60Hz, 1920x1080/60Hz, 1920x1200/60Hz
Operating temperature (T-T)0 - 40 °C
Product colorBlack, Grey
Converter type-
Weight and Dimensions IconWeight and Dimensions
Depth130 mm
Width150 mm
Height30 mm
Weight500 g
