Roland VC-1-SC User Manual

Panel Descriptions
16
Indicator Colors/Operation
SDI IN/OUT
Red SD-SDI input/output
Orange HD-SDI input/output
Green 3G-SDI input/output
SDI IN
Lighted Proper input
Flashing Input connector selected (no input)
SDI OUT
Lighted Proper output
Flashing Cannot output properly
HDMI IN/OUT
Red RGB input/output
Orange YCC 444 input/output
Green YCC 422 input/output
Flashing
Cannot input/output properly because of no HDCP support
or input connector selected (no input)
Unlighted Input connector unselected
AUDIO IN/OUT
Green/lighted -24 dB input/output
Red/lighted -6 dB input/output
REF IN
Lighted The unit locks to clock from the source device
Flashing Unsupported clock is input
Unlighted No input via REF IN (video input locked or free-run)

Roland VC-1-SC Specifications

General

Quantity	1
Cables included	AC
AC adapter included	Yes
Video in	SDI, HDMI, VGA
Video out	SDI, HDMI
Output interface	SDI/HDMI
Operating voltage	9 V
Maximum video resolution	1920 x 1200 pixels
Analog signal format system	NTSC, PAL
Supported resolutions	640x480/60/72/75/85Hz, 800x600/56/60/72/75/85Hz, 1024x768/60/70/75/85Hz, 1280x720/60Hz, 1280x768/60/75/85/Hz, 1360x768/60Hz, 1152x864/75Hz, 1400x900/60/75/85Hz, 1280x960/60/85Hz, 1280x1024/60/75/85Hz, 1400x1050/60/75Hz, 1680x1050/60Hz, 1600x1200/60Hz, 1920x1080/60Hz, 1920x1200/60Hz
Operating temperature (T-T)	0 - 40 °C
Product color	Black, Grey
Converter type	-

Weight and Dimensions

Depth	130 mm
Width	150 mm
Height	30 mm
Weight	500 g
