Roland VC-1-SC User Manual

18
Input Formats
RGB/YPbPr IN connector
YPbPr
1920 x 1080 60p, 59.94p, 50p, 60i, 59.94i, 50i, 24PsF, 23.98PsF
1280 x 720 60p, 59.94p, 50p
720 x 480 59.94p, 59.94i
720 x 576 50p, 50i
RGB
640 x 480 60, 72, 75, 85 Hz
800 x 600 56, 60, 72, 75, 85 Hz
1024 x 768 60, 70, 75, 85 Hz
1280 x 768 60, 75, 85 Hz
1360 x 768 60 Hz
1152 x 864 75 Hz
1400 x 900 60, 75, 85 Hz
1280 x 960 60, 85 Hz
1280 x 1024 60, 75 Hz
1400 x 1050 60, 75 Hz
1680 x 1050 60 Hz
1600 x 1200 60 Hz
1920 x 1200 60 Hz Reduced blanking
* RGB IN compatible only with input compliant with VESA DMT Version 1.0 Revision 11.
SDI IN connector
Video
1920 x 1080
60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p, 60i, 59.94i, 50i, 24PsF,
23.98PsF
1280 x 720 60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p
720 x 487 59.94i
720 x 576 50i
Audio Linear PCM, 24 bits/48 kHz, 16 channels
About Input/Output Formats

Roland VC-1-SC Specifications

General

Quantity	1
Cables included	AC
AC adapter included	Yes
Video in	SDI, HDMI, VGA
Video out	SDI, HDMI
Output interface	SDI/HDMI
Operating voltage	9 V
Maximum video resolution	1920 x 1200 pixels
Analog signal format system	NTSC, PAL
Supported resolutions	640x480/60/72/75/85Hz, 800x600/56/60/72/75/85Hz, 1024x768/60/70/75/85Hz, 1280x720/60Hz, 1280x768/60/75/85/Hz, 1360x768/60Hz, 1152x864/75Hz, 1400x900/60/75/85Hz, 1280x960/60/85Hz, 1280x1024/60/75/85Hz, 1400x1050/60/75Hz, 1680x1050/60Hz, 1600x1200/60Hz, 1920x1080/60Hz, 1920x1200/60Hz
Operating temperature (T-T)	0 - 40 °C
Product color	Black, Grey
Converter type	-

Weight and Dimensions

Depth	130 mm
Width	150 mm
Height	30 mm
Weight	500 g
