Roland VC-1-SC User Manual

About Input/Output Formats
19
HDMI/DVI IN connector
HDMI
1920 x 1080 60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p, 60i, 59.94i, 50i
1280 x 720 60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p
720 x 480 59.94p, 59.94i
720 x 576 50p, 50i
DVI
640 x 480 60, 72, 75, 85 Hz
800 x 600 56, 60, 72, 75, 85 Hz
1024 x 768 60, 70, 75, 85 Hz
1280 x 768 60, 75, 85 Hz
1360 x 768 60 Hz
1152 x 864 75 Hz
1400 x 900 60, 75, 85 Hz
1280 x 960 60, 85 Hz
1280 x 1024 60, 75 Hz
1400 x 1050 60, 75 Hz
1680 x 1050 60 Hz
1600 x 1200 60 Hz
1920 x 1200 60 Hz Reduced blanking
Audio Linear PCM, 24 bits/48 kHz, 8 channels
* The VC-1-SC supports HDCP (High-bandwidth Digital Content Protection system). When an
HDCP-applied signal is input, output is possible from only the HDMI OUT connector. Output from
the SDI OUT connector and AUDIO OUT connectors is stopped.
VIDEO IN jack
Video NTSC, PAL
AUDIO IN jacks
Analog audio
Nominal input level -6 dBV
Maximum input level +6 dBV
Input impedance 22 kΩ

Roland VC-1-SC Specifications

General

Quantity	1
Cables included	AC
AC adapter included	Yes
Video in	SDI, HDMI, VGA
Video out	SDI, HDMI
Output interface	SDI/HDMI
Operating voltage	9 V
Maximum video resolution	1920 x 1200 pixels
Analog signal format system	NTSC, PAL
Supported resolutions	640x480/60/72/75/85Hz, 800x600/56/60/72/75/85Hz, 1024x768/60/70/75/85Hz, 1280x720/60Hz, 1280x768/60/75/85/Hz, 1360x768/60Hz, 1152x864/75Hz, 1400x900/60/75/85Hz, 1280x960/60/85Hz, 1280x1024/60/75/85Hz, 1400x1050/60/75Hz, 1680x1050/60Hz, 1600x1200/60Hz, 1920x1080/60Hz, 1920x1200/60Hz
Operating temperature (T-T)	0 - 40 °C
Product color	Black, Grey
Converter type	-

Weight and Dimensions

Depth	130 mm
Width	150 mm
Height	30 mm
Weight	500 g
