Roland VC-1-SC User Manual

2
IMPORTANT: THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
BLUE:
BROWN:
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
Under no circumstances must either of the above wires be connected to the earth terminal of a three pin plug.
NEUTRAL
LIVE
For the U.K.

Roland VC-1-SC Specifications

General

Quantity	1
Cables included	AC
AC adapter included	Yes
Video in	SDI, HDMI, VGA
Video out	SDI, HDMI
Output interface	SDI/HDMI
Operating voltage	9 V
Maximum video resolution	1920 x 1200 pixels
Analog signal format system	NTSC, PAL
Supported resolutions	640x480/60/72/75/85Hz, 800x600/56/60/72/75/85Hz, 1024x768/60/70/75/85Hz, 1280x720/60Hz, 1280x768/60/75/85/Hz, 1360x768/60Hz, 1152x864/75Hz, 1400x900/60/75/85Hz, 1280x960/60/85Hz, 1280x1024/60/75/85Hz, 1400x1050/60/75Hz, 1680x1050/60Hz, 1600x1200/60Hz, 1920x1080/60Hz, 1920x1200/60Hz
Operating temperature (T-T)	0 - 40 °C
Product color	Black, Grey
Converter type	-

Weight and Dimensions

Depth	130 mm
Width	150 mm
Height	30 mm
Weight	500 g
