16
Names of Things and What They Do
Indicator Colors/Operation
SDI IN and THRU/OUT
Red SD-SDI input/output
Orange HD-SDI input/output
Green 3G-SDI input/output
SDI IN
Lighted Proper input
Flashing Unsupported signal is input
SDI OUT
Lighted Proper output
Flashing Cannot output properly
HDMI OUT
Red RGB output
Orange YCC 444 output
Green YCC 422 output
Flashing Cannot output properly because of no HDCP support, etc.
AUDIO IN/OUT
Analog in/out
Green/lighted -24 dB input/output
Red/lighted -6 dB input/output
AES in/out
Orange/lighted Proper input/output
Orange/ashing Cannot input/output properly
