17
Input Formats
SDI IN Connector
Video
1920 x 1080
60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p,
60i, 59.94i, 50i
1280 x 720 60p, 59.94p, 50p, 30p, 29.97p, 25p
720 x 487 59.94i
720 x 576 50i
Audio Linear PCM, 24 bits/48 kHz, 16 channels
AUDIO IN Connectors
Analog audio
Nominal input level +4 dBu
Maximum input level +24 dBu
Input impedance 150 k ohms
Digital audio
Format AES3, 24 bits/48 kHz, 2 channels
Input impedance 110 ohms
About Input/Output Formats
