Roland VC-1-SH User Manual

18
About Input/Output Formats
Output Formats
The VC-1-SH does not support up/down conversion, cross conversion, interlaced to progressive
(I/P) scan conversion, or frame rate conversion. See the Roland VC-300HD if you need this
functionality.
SDI THRU/OUT Connector
Video
1920 x 1080
60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p,
60i, 59.94i, 50i
1280 x 720 60p, 59.94p, 50p, 30p, 29.97p, 25p
720 x 487 59.94i
720 x 576 50i
Audio Linear PCM, 24 bits/48 kHz, 16 channels
HDMI OUT Connector
Video
1920 x 1080
60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p,
60i, 59.94i, 50i
1280 x 720 60p, 59.94p, 50p, 30p, 29.97p, 25p
720 x 487 59.94i
720 x 576 50i
Audio Linear PCM, 24 bits/48 kHz, 8 channels
AUDIO OUT Connectors
Analog audio
Nominal output level +4 dBu
Maximum output level +24 dBu
Output impedance 600 ohms
Digital audio
Format AES3, 24 bits/48 kHz, 2 channels
Output impedance 110 ohms
