Main Specication
Input/Output Formats
Refer to “About Input/Output Formats” (p. 17).
Input Connectors
SDI BNC type x 1
Analog Audio TRS phone type (balanced) x 1 pair (L/R)
Digital Audio TRS phone type x 1 (combination use with analog audio R-channel)
Output Connectors
SDI BNC type x 1
HDMI Type A (19 pins) x 1
Analog Audio TRS phone type (balanced) x 1 pair (L/R)
Digital Audio TRS phone type x 1 (combination use with analog audio R-channel)
Other Connectors
USB Type B (Hi-Speed USB) x 1
Signal Standards
SDI SMPTE 424M (SMPTE 425M-AB), SMPTE 292M, SMPTE 259M-C
Signal Level/Impedance
Analog Audio
Nominal Input Level +4 dBu
Maximum Input Level +24 dBu
Input Impedance 150 k ohms
Output Impedance 600 ohms
Digital Audio Input/Output Impedance 110 ohms
