Setting the Operation Mode
MODE SW 6/7
This species the audio channels assigned to signals from the AUDIO OUT
connectors. Combinations of 6 and 7 specify the assigned channels as described
below.
6 OFF 7 OFF Channels 1 and 2 assigned
6 OFF 7 ON Channels 3 and 4 assigned
6 ON 7 OFF Channels 5 and 6 assigned
6 ON 7 ON Channels 7 and 8 assigned
MODE SW 8
This selects the pre/post of audio embedding for SDI output.
OFF THRU. Signal before embedding (pre) is output.
ON OUT. Signal after embedding (post) is output.
MODE SW 9
This species the type of 3G-SDI output coming out from the SDI THRU/OUT
connector.
* The signal type of SDI IN is detected automatically.
OFF Output with Level A mapping structure
ON Output with Level B mapping structure
MODE SW 10
This species the control mode.
* This also enables/disables the AUTO OFF function (p. 13).
OFF Mode is controlled by switches 1-9..
ON
The unit operates according to the settings in the internal memory (Set with VC-1
RCS software)
You can carry out detailed settings and save to unit’s internal memory using the dedicated
remote control software, the VC-1 RCS (p. 25).
