Connecting External Equipment
Connecting a Digital Audio Source
Change the setting (p. 22) to input AES signals. When you are doing this, use only
the R-channel of AUDIO IN connectors. The L-channel is invalid when the setting is
changed to input AES signals.
g.digital-audio-connection.eps
Connecting Output Equipment
Connecting SDI Equipment
Connect a video deck or other equipment capable of SDI input to the SDI THRU/OUT
connector.
g.SDI-OUT-connection.eps
Connecting HDMI Equipment
Connect a TV monitor or other equipment capable of HDMI input to the HDMI OUT
connector.
g.HDMI-OUT-connection.eps
