3
Project
Parameter Value Explanation
COMMON
MstrTune
435.0–445.0Hz
Species the reference pitch (master tune) for
the project.
* This has no eect on the pitch of the VOCAL
track.
PC IN
These are the settings for audio input from a computer or
smartphone connected via USB.
PC Level 0–127
Species the input level from the USB PC IN
port.
PC Pan L128–127R Species the pan of the USB PC IN port.
COLOR Sets the pad illumination colors for each pad operation mode.
Note
ORANGE
YELLOW
GREEN
BLUE
PURPLE
PINK
WHITE
SKYBLUE
P.YELLOW
P.BLUE
P.PINK
L.RED
L.ORANGE
L.YELLOW
L.GREEN
P.GREEN
L.SKYBLUE
L.BLUE
L.PURPLE
Sets the color used for pads used for playing
in Note mode.
Play
Sets the color used to indicate that a clip is
playing back in Section Select mode.
Stay
Sets the color used to indicate that a clip has
stopped in Section Select mode.
D.Style
Sets the pad color used when a drum track
(KICK, SNARE, HI-HAT, KIT) is selected in Style
mode.
M.Style
Sets the pad color when a melodic track
(BASS, INST 1, INST 2) is selected in Style
mode.
Song
GEN
Parameter Value Explanation
Master Level 0–127 Adjusts the volume.
Key
NONE, C, C#, D, D#, E,
F, F#, G, G#, A, A#, B
Species the note
that will be the key of
the scale.
When a key or scale
is set for a clip and
the clip is loaded into
another project, the
clip is automatically
transposed to match
the MASTER KEY and
scale of the project.
Scale
Species the scale from which the chord is
extracted.
&
For details on scales, refer to “List of scales
(when KEY is C)” (p. 8).
TEMPLATE
Parameter Value Explanation
Intro
NONE, SECT1 - SECT 16
Sets the section to assign for the
structural elements of a song (like
the intro or the chorus) when using a
song template.
Verse1
Verse2
Verse3
Chorus1
Chrous2
Bridge
Outro
Fill
PreChorus
Breakdown
Vamp
User1
User2
User3
User4
TRANSPOS
Parameter Value Explanation
KICK Trans
ON, OFF
Sets whether the clip’s key/scale are
automatically changed to follow the
key/scale that are set for the song.
Set this to “ON” to make the clip’s
key/scale follow the song’s settings.
* This is only enabled when the track
type is “tone”.
SNARE Trans
HIHAT Trans
KIT Trans
BASS Trans
INST1 Trans
INST2 Trans
Tone Edit
Parameters with the “
ASSIGN
” showing can be assigned to the knob.
Parameter Value Explanation
Level
ASSIGN
0–127 Adjusts the volume of each part.
Pan
ASSIGN
L64–0–63R
Species the panning of each part’s sound when
using stereo output.
Delay Send
(Delay Send Level)
ASSIGN
0–127 Species the send level to delay.
Reverb Send
(Reverb Send Level)
ASSIGN
0–127 Species the send level to reverb.
Coarse Tune
ASSIGN
-48–+48 Shifts the pitch in units of a semitone.
Fine Tune
ASSIGN
-50–+50 Finely adjusts the pitch in units of one cent.
Mono/Poly
MONO, POLY,
TONE
Choose MONO if you want the tone assigned to
the part to play monophonically; choose POLY if
you want to play it polyphonically.
Choose TONE if you want to use the setting
specied by the tone.
Legato
(Legato Switch)
OFF, ON,
TONE
If you play monophonically, you can apply legato.
“Legato” is a performance technique that smoothly
connects one note to the next. This produces an
eect similar to hammering-on or pulling-o when
playing a guitar.
Choose “ON” to apply legato, or “OFF” if you don’t
want to apply it.
Choose “TONE” if you want to use the setting
specied by the tone.
Bend Range 0–24, TONE
Species the amount of pitch change in semitone
units (maximum two octaves) that occurs when
you move a controller when pitch bend is assigned
to that controller.
Choose TONE if you want to use the setting
specied by the tone.
Portament
(Portamento
Switch)
ASSIGN
OFF, ON,
TONE
Species whether portamento is applied. Select
ON to apply portamento, or OFF if you don’t want
to apply portamento.
Choose TONE if you want to use the setting
specied by the tone.
Porta Time
(Portamento Time)
ASSIGN
0–127, TONE
When portamento is used, this species the time
over which the pitch will change. Higher settings
will cause the pitch change to the next note to take
more time.
Choose TONE if you want to use the setting
specied by the tone.
Cuto
(Cuto
Oset)
ASSIGN
-64–+63
Adjusts how far the lter is open.
Increasing this value makes the sound brighter,
and decreasing it makes the sound darker.
Resonance
(Resonance Oset)
ASSIGN
-64–+63
Emphasizes the portion of the sound in the region
of the cuto frequency, adding character to the
sound. Excessively high settings can produce
oscillation, causing the sound to distort.
Increasing this value strengthens the character,
and decreasing it weakens the character.
Attack
(Attack Time Oset)
ASSIGN
-64–+63
Adjusts the time over which the sound reaches its
maximum volume after you press the key.
Larger settings of this value make the attack
gentler, and smaller settings make the attack
sharper.
Parameter List
