5
Parameter List
Parameter Value Explanation
High Gain -24–+24 [dB] Gain of the high frequency range.
HighFreq 20–16000 [Hz] Frequency of the high range.
COMP
(Other than VOCAL)
Parameter Value Explanation
Switch OFF, ON Compressor on/o
Pos Pre MFX, Post MFX Location of the compressor.
Attack 0.1–100 [ms]
Time from when the input exceeds the
threshold until compression begins
Release 10–1000 [ms]
Time from when the input falls below the
threshold until compression is turned o
Thres -60–0 [dB] Level at which compression is applied
Ratio 1: 1–inf: 1 Compression ratio
Knee 0–30 [dB]
This is a function that smooths the onset of
compression from the uncompressed state; it
gradually applies compression starting earlier
than Threshold. Higher values produce a
smoother transition.
Gain -24–+24 [dB] Level of the output sound
Out Asgn DRY, MFX Species the compressor output destination.
MIDI
(Other than VOCAL)
Parameter Value Explanation
TxMIDI Out OFF, ON
Enables output to the rear panel MIDI OUT
connector.
TxUSB MIDI OFF, ON Enables output to the rear panel USB port.
Tx Note OFF, ON
Species whether the notes of each track are
output.
* This is not shown for a looper track.
Tx CC OFF, ON
Species whether knob operations of each
track are output.
Tx PC OFF, ON
Species whether clip changes of each track
are output.
CLIP SETTING
Parameter Value Explanation
Mix Level 0–127 Adjusts the volume of each part.
Pan L64–0–63R
Species the panning of each part’s sound
when using stereo output.
Delay Send 0–127 Species the send level to delay.
Rev Send 0–127 Species the send level to reverb.
Shue
(*1) -50–+50
Adjusts the strength of shue (bounce) for
the playback timing.
This can be set individually for each clip.
Step Length 1–128 Species the length of the clip.
Scale
(*1)
1/8,
1/16,
1/32,
1/4T,
1/8T,
1/16T
Species the step resolution.
1/8: eighth notes
1/16: sixteenth notes
1/32: thirty-second notes
1/4T: quarter note triplets
1/8T: eighth note triplets
1/16T: sixteenth notes triplets
Mode
(*1)
FWD,
REV,
FWD+REV,
INV,
RND
Species how the sequence plays.
FWD: Play forward from the rst step.
REV: Play backward from the last step.
FWD+REV: Play forward from the rst
step, and after reaching the last step, play
backward.
INV: Play even numbers and odd numbers
inverted.
RND: Play randomly.
Qtz C.Tight
(*1) OFF, 1–100 %
Species the strength of quantization for the
currently selected clip.
Quantization is applied during playback.
Transpose (*1) -12–+12 Shifts the playback transposition (Tone only).
Parameter Value Explanation
Reverse
(*2) OFF, ON
OFF: The sample plays forward.
ON: The sample plays backward.
Pad Octave -5–+5 Species the octave for pad performance.
Bend Mute
(*1) OFF, MUTE Disables bend (Tone only).
Key
NONE, C, C#, D, D#, E,
F, F#, G, G#, A, A#, B
Species the note
that will be the key of
the scale.
When a key or scale
is set for a clip and
the clip is loaded into
another project, the
clip is automatically
transposed to match
the MASTER KEY and
scale of the project.
Scale
Species the scale from which the chord is
extracted.
&
For details on scales, refer to “List of scales
(when KEY is C)” (p. 8).
*1 Valid when the track type is set to other than LOOPER.
*2 Valid when the track type is set to LOOPER
LOOPER SETTING
Parameter Value Explanation
Level 0–127
Species the volume at which the sample
plays.
Pan L63–63R Species the pan of the sound.
Delay Send 0–127
Adjusts the amount sent to the total eect
delay.
Reverb Send 0–127
Adjusts the amount sent to the total eect
reverb.
Pitch Chrom -24–+24
Species the pitch in semitone steps
(maximum ±2 octaves).
This setting can also be made in PAD MODE
NOTE.
Pitch Fine -100–+100 Finely adjusts the pitch.
Pitch Shift 0–400 % Smoothly modies the pitch in a wide range.
PitchStrch OFF, TYPE1, TYPE2
Selects the pitch shift / time stretch method.
OFF: Time stretch is not used; the sample is
lengthened by changing its pitch.
* If OFF is selected, the settings in the PITCH tab
are ignored (pitch shift is not applied).
TYPE1: Time stretch optimized for melodic
material is applied.
TYPE2: Time stretch optimized for rhythm
material is applied.
Str Window
1.0, 0.75, 0.5, 0.375,
0.25
This parameter applies to time stretch.
Higher values improve the audio quality.
If an unnatural impression results when pitch
shift or time stretch is used to create a large
amount of change, lowering this value might
improve the result.
Reverse OFF, ON
OFF: The sample plays forward.
ON: The sample plays backward.
MEAS EDIT (Only LOOPER)
Parameter Value Explanation
Step Length 1–128
Species the length of the clip.
* The same setting can also be made in the CLIP
settings screen ([SHIFT] + [CLIP]).
Reverse OFF, ON
Species the sample playback method.
* The same setting can also be made in the CLIP
settings screen ([SHIFT] + [CLIP]).
SAMPLE EDIT Parameter
Parameter Value Explanation
Start 0– Sets where to start playback.
End 0– Sets where to end playback.
Norm Level -12–0dB
Sets the peak value (maximum) for the
normalized waveform.
NORMALIZE EXEC —
Press the [VALUE] dial to normalize.
Normalization automatically raises the
volume to the range where the sound does
not distort.
Slice Level HARD, MID, SOFT Sets the slice sensitivity.
To Next Page
