Bread slicer C42 – C42S – C52 – C52S – G42
(Original instructions) – Edit. A
11
Figure 7
Loading/unloading from the transport vehicle is normally carried out by means of a forklift truck or
pallet truck having a sufficient lifting capacity, and whose arms must be inserted in the special spaces
at the bottom of the pallet. Remove the machine’s packaging; check that it is in good condition and
intact; separate the materials by type (cardboard, plastic, wood, etc.), depositing them in special
collection sites accessible only to authorized persons, so that they are ready for collection by
specialist waste disposal companies. The wooden joists and pallet must also be taken to a specially-
designated collection site.
Environmental respect is a duty enshrined in current legislation.
Figure 8
After positioning the machine, block the two wheels fitted with brakes by lowering the respective
levers (Figure 8).
3.2.1 MOUNTING THE MACHINE ON THE SUPPORT TROLLEY
(MOD. C42-C52-G42)
After having assembled the support trolley, block the two wheels fitted with a braking device, Figure
9, place the machine on the support and fix it to the trolley from the inside with the screws provided.
* Block the machine on the support with the screws provided, inserting them in the central threaded
holes in the feet.
Figure 9
