Bread slicer C42 – C42S – C52 – C52S – G42
(Original instructions) – Edit. 02/2013 – Rev.A
Both types C and C-S come in two different models that vary in the maximum length (L
max
) of the
loaf of bread that can be cut:
Model 42 → L
max
= 420 mm (identifications C42 and C42S)
Model 52 → L
max
= 520 mm (identifications C52 and C52S)
Types C and C-S may be supplied in the version WITH BLADE LUBRICATION which,
however, must be explicitly requested by the customer at the time of ordering the machine, as it is not
possible to fit the system later; the lubrication system consists substantially of a felt kept wet with
food-grade oil in which the blades run so that they are kept lubricated with a film of oil (see Par.
3.4.4).
Type G42: machine similar to mod. C42 basic (Figure 1) but with a lower power, also to be used on a
surface 750-800 mm above the ground (e.g. a table); the bread is cut by activating the manual control
lever.
Maximum length of the loaf of bread that can be cut L
max
= 420 mm.
All the types and models described so far can be supplied in a version WITH COVER, that is with
a steel top guard protecting the area of movement of the bread-pusher, ref. 2 Figure 2; the guard
opens and closes by activating the control lever ref. 5 Figure 1. As regards the risk represented by
the blades, the basic version of the machine complies with safety requirements; however, by
choosing this version, the customer can ensure an even higher level of safety for its operators; in fact,
the blades only start moving when the cover is completely closed. In this case too, however, the
device must be explicitly requested by the customer at the time of ordering the machine, as it is not
possible to fit it later.
Version with cover Support trolley
Figure 3
Figure 4
On request and only for models C42, C52, G42, a support trolley may be supplied on which to fix
the machine; the trolley has four wheels, two of which with a braking system (see Par. 3.2.1)
