RS232control mode
1. A serial port connection
1.1Port setting item
Item Set value
Communication method asynchronous communication
Communication speed
19200
Long digits 8 location
odd-even check
NO
stop bit 1
traffic control
NO
1. 2 Wired way
can only use RS232 Serial cross cable connection PC and the prjector。
Computer side the projector side
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
CD
SG
RXD
TXD
DTR
DSR
RTS
CTS
RIN
G
RXD
TXD
SG
RTS
CTS
N.C.
N.C.
N.C.
N.C.
1.
A serial port command：
Case - sensitive, and each command[
CR
] ( return key ) For the end symbol。
order option order option
C00
POWER ON
C01
POWER OFF
C10
Image mode - standard
C11 dynamic condition
C12 movie theatre
C13
DICOM
C14
The color board
- red
C15
The color board
- green
C16
The color board
- blue
C17
The color board
- yellow
