Quick Start Reference – Calibrating Density
Step 1 Start at the Status Display
From the Status Display Screen, Press the F3 (Lock) Key to display
the Password Screen (or the Main Menus if the password is
disabled).
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Enter Password:
******
All0
RST0
EXIT
ENTER
C
F1 F2 F3 F4
Ronan Engineering
X96S Mass Flow Gauge
Status Display
Mass Flow 3.05 t/hr
Density 2.5 SPG
Proc Temp 50.00 deg
Raw Counts 12000
Filt.Counts 12000
Time 04/20/05 08:05
Diagnostics
Step 2 Password Menu
With the left most character * highlighted (All digits are set
at 000000 at this point), enter in the password ‘101010’.
Press the ↑ key 1 time to make the left most character
equal to 1. Press the → key 2 times to move to the third
character.
Press the ↑ key 1 time to make the third character equal to
1. Press the → key 2 times to move to the fifth character.
Press the ↑ key 1 time to make the fifth character equal to
1. Press the F4 key (enter) to accept the password.
This will take you to the Main Menu.
Note: If the wrong password was entered, press the F1
(All0) to set all the characters back to a value of 000000.
You can begin to re-enter the password from the beginning.
Pressing the F2 (RST0) will set the individual character that
is highlighted back to the value 0.
Note: For security reasons, each character will always be
displayed as an asterisk *.
To Next Page
