Controller functions
Version 1 RES-403 Page 37
Part 3 of 3: Error messages as of October 2005 (warnings)
NOTE:
The specified error messages are initially output as warnings (actual value output jumps back and forth
between two values, alarm LED blinks, alarm relay de-energized). When the "START" signal is activated, the
warning changes to a fault (actual value output no longer jumps back and forth, see bold italic values, alarm
LED lit continuously, alarm relay energized).
Error
code
Act. val.
output
voltage
[V]
Cause
Action if machine
started for first time
Action if machine
already operated, HS
band not changed
111
6.66
10
Current signal incorrect,
no calibration possible
Fault area
,
check configuration
Fault areas
("loose contact")
112
7.33
10
Voltage signal incorrect,
no calibration possible
Fault area
,
check configuration
Fault areas
("loose contact")
113
8.00
10
Current / voltage signals incor-
rect,
no calibration possible
Fault area
,
check configuration
Fault areas
("loose contact")
114
8.66
10
Temperature fluctuates,
no calibration possible
Perform AUTOCAL
and / or
fault areas
("loose contact")
Perform AUTOCAL
and / or
fault areas
("loose contact")
115
Ext. calibration temp. too high,
no calibration possible
Perform AUTOCAL with
ext. calibration tempera-
ture ≤40°C
Perform AUTOCAL with
ext. calibration tempera-
ture ≤40°C
116
Ext. calibration temp. fluctu-
ates,
no calibration possible
Perform AUTOCAL with
stable ext. calibration
temperature
Perform AUTOCAL with
stable ext. calibration
temperature
