Rosco Maximizer 3B User Manual

10
Rosco Maximizer 3B Asphalt Distributor 10-11
Illustrated Parts List (IPL)
Asphalt Pump Parts List
Item
No. Part Number Qty. Description Remarks
4165-16 1 Asphalt Pump, Viking
2 5257 1 •Packing Gland
3 5249 1 •Packing,10 Pcs Per Pack
4 32821 1 •Packing Retainer Washer
5 5247 1 •Rotor Bearing Sleeve Bushing Only
6 5250 1 •Rotor Bearing With Bushing Sleeve
7 6541 1 •Rotor Bearing Sleeve Gasket
8 5240 1 •Casing
9 1488 1 •Gasket,Flange,4.00
10 5251 1 •Rotor Bearing Sleeve Washer
11 5248 1 •Rotor Thrust Washer
12 5241 1 •Rotor And Shaft
13 5244 1 •Idler With Bushing
14 5255 1 •Idler Bushing Only
15 5246 1 •Head Gasket Set
17 6313 1 •Head With Idler Pin
19 6314 1 •Relief Valve Gasket Set
20 6315 1 •Relief Valve Assy (See Fig 1-4)
Return to
Last Viewed
Return to
Thumb Index
