Rosco Maximizer 3B User Manual

10
Rosco Maximizer 3B Asphalt Distributor 10-27
Illustrated Parts List (IPL)
Hydraulic, Front Live Parts List
Item
No. Part Number Qty. Description Remarks
26126 1 Hydraulic, Front Live
1 15795 1 •Fitt,Plug,12Mb,Hex,W/04Fp
2 15984 1 •Support,Filter
3 17211 2 •Bar,.250X3.00x5.00
4 22490SRV 1 •Reservoir,Installation,20 Gal
5 23363 2 •Bracket,Hydraulic Line
6 6250 2 •Fitt,90,16Mj-12Mb
7 32592 40 •Hose,16,Suction,250
8 33148 1 •Strainer,Suct,2Npt,25Gpm,100Me
9 33162 2 •Clamp,Hose,.44-.78,Worm,#06
10 33164 2 •Clamp,Hose,.56-1.06,Worm,#10
11 33167 4 •Clamp,Hose,.81-1.75,Worm,#20
12 33275 1 •Fitt,Str 04Mb-04Fpx
13 33307 1 •Fitt,90 10Mj-12Mb
14 33365 1 •Fitt,90 04Mp-06Hb,Crimped
15 33863 1 •Hose Assy,1500 Psi,-10X34.00
16 33887 1 •Fitt,Str 16Mj-16Mb
17 34083 1 •Fitt,90 12Mj-10Mb
18 34463 1 •Filter,Return,Hp,-12Sae Ports
-1801 34464 1 ••Filter Element,Hyd (Element Only)
-1802 35269 1 ••Gauge,Sight Lh Visual (Restriction Indicator)
19 33781 1 •Fit,90,16Mj-20Mp
20 34799 10 •Clamp,Loop,1.562 Od,Nprn Cover
21 X329 1 •Fitt,Tee 16Mj-16Mb-16Mj
22 23383SRV 1 •Tube Assy,Hydraulics,Max Ii
23 35067 3 •Hose Assy,4000 Psi,-16 X 45.00
24 35068 1 •Hose Assy,4000 Psi,-16 X 21.00
25 34861 4 •Cover Plate,Hose Clamp
26 34860 8 •Clamp,Half,Hose,.750
27 35543 4 •Weld Plate
29 38208 60 •Hose,08,Hyd,3000
30 38209 4 •Fitt,Hes,08Fj-08Hb,Fld Crmp
31 36077 4 •Fitt,Str 16Mj-16Mh
32 36167 4 •Clamp,Tube,1.00 Od Twin,Set
33 36606 2 •Fitt,Hes,16Fj-16Hb,Fld Crmp
34 37245 4 •Fitt,90 16Mj-16Mj
35 6342 2 •Fitt,Str 12Mp-16Hb,Crimped
36 6351 1 •Vlv,Check,08 Npt,20 Psi Crack
