Rosco Maximizer 3B User Manual

10
Rosco Maximizer 3B Asphalt Distributor 10-43
Illustrated Parts List (IPL)
Drive Shaft Group Parts List
Item
No. Part Number Qty. Description Remarks
Driveshaft
34851-20SRV 1 Front Live Power
International Trucks
-1 39105 1 •Driveshaft,Flange,1350
-2 39107 1 •Solid Shaft Assembly
-3 39111 1 •Driveshaft,End Yoke,15T Spln
-4 39112 2 •Driveshaft,Set Screw W/Wire Lk
34851-42SRV 1 Front Live Power
Ford, Sterling, Freightliner, GMC Trucks
-1 39104 1 •Driveshaft,Flange,1310
-2 39107 1 •Solid Shaft Assembly
-3 39111 1 •Driveshaft,End Yoke,15T Spln
-4 39112 2 •Driveshaft,Set Screw W/Wire Lk
34850-XXX 1 PTO, Varies Per Truck
-1 39109 1 •Driveshaft,End Yoke,1.25 W/5/16
-2 39108 1 •Driveshaft,2” Tube,55 3/4
-3 39111 1 •Driveshaft,End Yoke,15T Spln
-4 39112 2 •Driveshaft,Set Screw W/Wire Lk
