Rosco Maximizer 3B Asphalt Distributor 10-49
Illustrated Parts List (IPL)
Spraybar Assembly, 16 Foot Parts List
Item
No. Part Number Qty. Description Remarks
25961 1 Spraybar Assembly, 16 Foot
1 15929 2 •Nut
2 28631 2 •Extension,Spraybar
3 25901 2 •Spraybar W/M,Extendable
4 25944 1 •Support,Spraybar,Rh
5 25948 4 •Link,Support,Bottom
-6 25949 1 •Support,Spraybar,Lh
7 25997SRV 4 •Link,Support,Top
8 26016 2 •Mount,Motor,Spraybar
9 26017 2 •Rail,Barslide,Top
10 26019 1 •Barslide W/M
11 26033 2 •Plate,Slide
12 26034 2 •Block,Slide,Bottom
13 26035 2 •Block,Slide,Top
14 26036 2 •Rack,Gear,8 D.P.,Modied
15 26059 2 •Shaft,Thd’d,1.75
16 26060 2 •Washer,Sq,.281Idx1.5
17 26106 4 •Block,Stop,Extend
18 26112 2 •Rail,Barslide,Bttm
19 26141SRV 2 •Pot Assembly,Max3
20 26142 2 •Plate,Access
21 27594 1 •Bracket,Actuator
22 28540 1 •Control Grp,Air,Max3
Attaching Parts
1 ••Wiring Diagram
-2201 37311 48 ••Fitt,90 02Mp-02Fp,Brass
-2202 38130 24 ••Valve,3 Way,Air,Spray Bar (No Seal Kit Available)
-2203 38132 24 ••Valve,3 Way,02X02x02, (No Seal Kit)
-2204 38201 296 ••Clamp,Hose,Band,.45Dia
-2205 38412 4 ••Fitt,Tee 04Hb-O4hb-04Hb,Brass
-2206 5347 235 ••Hose,04,Push-On,Low Pressure
-2207 71796 14 ••Fitt,90 02Mp-04Hb,Crimped,Bras
-2208 72700 130 ••Fitt,Tee 04Hb-04Hb-02Mp,Brass
-2209 90803 22 ••Sleeve,Abrasion,Nylon,1.75Id
23 26469 48 •Spray Valve Assembly,Max3
24 35565 48 •Nozzle #00
24 32917 A/R •Nozzle #0
24 32918 A/R •Nozzle #1, 5 Gpm/40 Psi
