Rosco Maximizer 3B Asphalt Distributor 10-61
Illustrated Parts List (IPL)
Valve Box, Subassembly Parts List
Item
No. Part Number Qty. Description Remarks
28274 1 Valve Box, Subassembly
2 1002015 1 •Plate,Vlv,Max3
4 38123 1 •Manifold,Hyd,4 Sta,3 Vlv,W/Rel
Attaching Parts
-401 37488-01 A/R ••Valve
-402 37488-03 1 ••Relief Valve
-403 37488-04 1 ••Bolt Kit,For Valve
-404 37488-05 2 ••Cover Plate,Includes Bolts
-405 37488-06 1 ••Coil,For Valve
5 38815 1 •Vlv,Sol,Air,8 Pos,Assy,1 Cv Single
38722-01 Solenoid Air Valve Not Shown
-501 38815-01 A/R ••Manifold,8 Pos,Air
6 480160 1 •Vlv,Ball,.375
7 31959 1 •Fitt,Str 06Mp-06Hb,Push-On
8 38579 10 •Hose,06,Low Press Push On
9 33162 4 •Clamp,Hose,.44-.78,Worm,#06
10 33365 1 •Fitt,90 04Mp-06Hb,Crimped
11 37049 1 •Vlv,Press Protection,102-88
12 99591 1 •Pipe,Nipple,04Xclose(7/8)
13 99980 1 •Pipe,Bush,08Mp-04Fp,Stl
16 36481 2 •Tubing,Air Brake,Blk,08
19 70957 6 •Fitt,Str 04Fjx-04Hb,Push-On
20 80140 5 •Washer,Type A Plain,.250
21 80192 3 •CSHH,.250-20X.75,Gr5
22 80350 5 •Nut,Flexloc,.250-20,Full,Lt
23 80995 4 •Washer,Type A Plain,#10
24 80824 3 •Nut,Hex,#10-24
25 81146 2 •Mach Scr,Ph,#10-24 X 1.50
26 80196 2 •CSHH,.250-20X2.00,Gr5
29 38913 1 •Fitt,Str 06Mp-08Nt
30 38914 2 •Fitt,Tee 08Nt
31 71716 1 •Mach Scr,Ph,#10-24X.75
32 28956 1 •Harness,Wire,Vlv Box,Max3
33 1001822-01 1 Controller, 50 pin module
34 1001822-02 1 Controller, 24 pin module LH Spraybar
35 1001822-03 1 Controller, 24 pin module RH Spraybar
50 28954 1 •Sheet, Blanking
