Rosco Maximizer 3B User Manual

10
Rosco Maximizer 3B Asphalt Distributor 10-79
Illustrated Parts List (IPL)
Tank Top Opening Parts List
Item
No. Part Number Qty. Description Remarks
TBD 1 Tank Top Opening
1 20162 2 •Top Opening Cover Latch
2 20165 1 •Top Opening Cover Cross Bar
3 20167 1 •Top Opening Cover Retainer
4 20168 1 •Top Opening Cover
5 36062 1 •Top Opening Cover Gasket
6 6066 2 •Top Opening Cover Knob
7 8530 2 •Eyebolt
8 71716 2 •Pan Head Screw,#10-24 Unc X3/4
9 871071601 2 •Washer,Lock,#10
10 80348 4 •Roll Pin,.500X1.50
11 80354 4 •Nut,Flexloc,.500-13,Full,Lt
12 80076 4 •Nut,Hex,Jam,.500-13
13 80255 2 •CSHH,.500-13X2.00,Gr5
14 20166 4 •Thd’d Rod,.500-13X3.25
-15 21282 1 •Top Opening Screen Assembly,Full
-50 23514 1 •Manhole Screen
