Rosco Maximizer 3B Asphalt Distributor 10-97
Illustrated Parts List (IPL)
Spraybar Assembly, 18 FT Parts List
Item
No. Part Number Qty. Description Remarks
28762 1 Spraybar Assy, 18 Foot
1 15929 2 •Nut
2 15930 2 •Cap,End,Spraybar
3 25901 2 •Spraybar W/M,Extendable
4 25944 1 •Support,Spraybar,Rh
5 25948 4 •Link,Support,Bottom
-6 25949 1 •Support,Spraybar,Lh
7 25997 4 •Link,Support,Top
8 26016 2 •Mount,Motor,Spraybar
9 26017 2 •Rail,Barslide,Top
10 26019 1 •Barslide W/M
11 26033 2 •Plate,Slide
12 26034 2 •Block,Slide,Bottom
13 26035 2 •Block,Slide,Top
14 26036 2 •Rack,Gear,8 D.P.,Modied
15 26059 2 •Shaft,Thd’d,1.75
16 26060 2 •Washer,Sq,.281Idx1.5
17 26106 4 •Block,Stop,Extend
18 26112 2 •Rail,Barslide,Bttm
19 26141 2 •Pot Assembly,Max3
20 26142 2 •Plate,Access
21 27594 1 •Bracket,Actuator
22 28764 1 •Control Grp,Air,Max3,18’ Bar Uses Hose Pn 5347
Attaching Parts
-2201 33343 8 ••Fitt,Str 02Mp-04Hb,Push-On
-2202 35924 4 ••Fitt,Plug 02Qd
-2203 35925 4 ••Socket,Quick Coupler,02Npt
-2204 37311 48 ••Fitt,90 02Mp-02Fp,Brass
-2205 38130 24 ••Valve,3 Way,Air,Spray Bar (No Seal Kit Avail.)
-2206 38132 30 ••Valve,3 Way,02X02x02 (No Seal Kit)
-2207 5347 235 ••Hose,04,Push-On,Low Pressure
-2208 38201 320 ••Clamp,Hose,Band,.45Dia
-2209 38412 4 ••Fitt,Tee 04Hb-O4hb-04Hb,Brass
-2210 71796 16 ••Fitt,90 02Mp-04Hb,Crimped,Bras
-2211 72700 146 ••Fitt,Tee 04Hb-04Hb-02Mp,Brass
-2212 90803 22 ••Sleeve,Abrasion,Nylon,1.75Id
23 26469 54 •Spray Valve Assembly,Max3 (See Fig 7-5)
24 35565 54 •Nozzle #00
