Rosco Maximizer 3B Asphalt Distributor 10-123
Illustrated Parts List (IPL)
Item
No. Part Number Qty. Description Remarks
Attaching Parts
3701 38216-01 1 ••Bracket,Igniter & Flame Rod
3702 38216-02 1 ••Igniter/Flame Rod
38 28539 1 •Tab,Mt Piping Bracket
39 37241-07 1 •Solenoid
40 37241-08 3.17 •Ignition Wire
42 37241-10 1 •Harness,Wiring
43 71716 4 •Mach Scr,Ph,#10-24X.75
44 71720 4 •Mach Scr,Ph,#10-32X.38
45 81005 4 •Nut,Flexloc,#10-24,Full,Lt
46 871071601 4 •Washer,Lock,#10
47 37421 2 •Term,Solder Splice,22-14 Awg
48 35123 2 •Term,Ring,16-14 Ga,#6 Stud
49 72203 1 •Term,Push-On,.18,Fem,16-14 Ga
50 851390204 2 •Term,Ring,16-14 Ga,#10 Stud
51 33600 4 •Term,Push-On,.25,Fem,16-14 Ga
52 33271-1 7 •Wire,16 Ga,Black
54 80352 6 •Nut,Flexloc,.375-16,Full,Lt
55 80142 6 •Washer,Flat,Uss,.375
56 X126 1 •Fitt,Str 04Mp-04Fpx
57 985000 1 •Bar,Lp Line Brkt,S-Shaped
58 7640 1 •Brkt,.250 Pipe
59 99636 2 •Nipple,04X11.00,Std
60 99490 1 •Pipe,Cplg,04Fp
61 985812 1 •Pipe,Nipple,04X36.00
-100 23507 2 Flue Liner W/M, Lp Burner, Sst
LPG Burners, Double Flue, Auto Ignition (continued) Parts List
